As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Nissan, VQ35HR, 3.760 in. Bore, 8.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.760 Bore, 1.198 CD, 0.866 Pin, Set of 6. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Nissan VQ35HR, 95.50 Bore, Dish, Set of 6 |
| Description_SHO |
Piston Kit |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Nissan VQ35HR Piston Kit - 95.50 mm Bore - 1.198 in. CH, -13.00 CC |
| Industry |
Automotive |
| Add-On |
866-063-MW |
| Cylinder Head |
VQ35HR |
| Add-On |
866-2250-15-51C |
| Piston Material |
2618 |
| Add-On |
JG1001-3760 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Second Compression Ring Thickness |
0.0480 |
| Piston Head Type |
Dish |
| Piston Pin Length |
2.250 |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Engine |
VQ35HR |
| Ringset Included |
Yes |
| Make - Web |
Nissan |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.198 |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.111 |
| Make |
NISSAN |
| Top Compression Ring Thickness |
0.0400 |
| Piston Quantity |
6 |
| Title |
JE Pistons - Nissan, VQ35HR, 95.50 mm Bore, Piston Kit |
| Product Market |
Sport Compact |
| Bore Diameter |
95.50 |
| Piston Series |
JE Pistons |
| Piston Volume |
-13.00 |
| Piston Pin Outside Diameter |
0.866 |
| Engine Type |
ICE |
| Piston Average Weight |
371 |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Type |
Engine Piston Kit |
| Engine - Web |
VQ35HR |
| Ring Set Included |
Yes |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
