As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ205 Stroker |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.622 Bore, 1.209 CD, 0.905 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Subaru, EJ Series, 3.622 in. Bore, 9.50:1, Inverted Dome/Dish, Left Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Description_TLE |
Subaru EJ205, 92.00 Bore, Dish, Set of 1 |
| Description_INV |
JE Pistons, Piston |
| Add-On |
905-042-CT |
| Add-On |
905-2250-18-51S |
| Add-On |
JG1001-3622 |
| Cylinder Head |
EJ205 WRX |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Engine |
EJ SERIES |
| Bore Diameter |
92.00 |
| Compression Height |
1.209 |
| Engine - Web |
EJ Series |
| Forging Type |
FSR |
| Industry |
Automotive |
| Engine Type |
ICE |
| Make |
SUBARU |
| Oil Ring Thickness |
0.111 |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dish |
| Piston Average Weight |
338 |
| Make - Web |
Subaru |
| Title - Web |
JE Pistons Subaru EJ Series Piston - 92.00 mm Bore - 1.209 in. CH, -6.40 CC |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.250 |
| Title |
JE Pistons - Subaru, EJ Series, 92.00 mm Bore, Piston |
| Piston Quantity |
1 |
| Piston Pin Outside Diameter |
0.905 |
| Product Market |
Sport Compact |
| Piston Series |
JE Pistons |
| Product Type |
Engine Piston |
| Piston Orientation |
Left |
| Ringset Included |
Yes |
| Piston Material |
2618 |
| Piston Volume |
-6.40 |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.180 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.180 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
