As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ205 Stroker |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.661 Bore, 1.209 CD, 0.905 Pin, Set of 4. |
| Description_EXT |
JE, Subaru, EJ Series, 3.661 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Subaru EJ205, 93.00 Bore, Dish, Set of 4 |
| Ring Set Included |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.250 |
| Piston Material |
2618 |
| Piston Volume |
-16.00 |
| Second Compression Ring Thickness |
0.0480 |
| Piston Quantity |
4 |
| Make - Web |
Subaru |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Title - Web |
JE Pistons Subaru EJ Series Piston Kit - 93.00 mm Bore - 1.209 in. CH, -16.00 CC |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
EJ205 WRX |
| Bore Diameter |
93.00 |
| Add-On |
905-042-CT |
| Industry |
Automotive |
| Add-On |
905-2250-18-51S |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Add-On |
JG1001-3661 |
| Engine |
EJ SERIES |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
356 |
| Piston Pin Material |
5115 |
| Ringset Included |
Yes |
| Compression Height |
1.209 |
| Piston Head Type |
Dish |
| Piston Series |
JE Pistons |
| Forging Type |
FSR |
| Piston Pin Outside Diameter |
0.905 |
| Piston Pin Wall Thickness |
0.180 |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.111 |
| Piston Pin Length |
2.250 |
| Make |
SUBARU |
| Title |
JE Pistons - Subaru, EJ Series, 93.00 mm Bore, Piston Kit |
| Engine - Web |
EJ Series |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.905 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
