As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ205 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Subaru, EJ Series, 3.642 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.642 Bore, 1.287 CD, 0.905 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Subaru EJ205, 92.50 Bore, Dish, Set of 4 |
| Oil Ring Thickness |
0.111 |
| Forging Type |
FSR |
| Make |
SUBARU |
| Engine Type |
ICE |
| Piston Average Weight |
363 |
| Piston Series |
JE Pistons |
| Piston Pin Wall Thickness |
0.180 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Bore Diameter |
92.50 |
| Product Market |
Sport Compact |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.905 |
| Piston Volume |
-11.70 |
| Compression Height |
1.287 |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Piston Pin Outside Diameter |
0.905 |
| Title |
JE Pistons - Subaru, EJ Series, 92.50 mm Bore, Piston Kit |
| Piston Pin Material |
5115 |
| Piston Quantity |
4 |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Engine - Web |
EJ Series |
| Add-On |
JG1001-3642 |
| Piston Pin Length |
2.250 |
| Cylinder Head |
EJ205 WRX |
| Title - Web |
JE Pistons Subaru EJ Series Piston Kit - 92.50 mm Bore - 1.287 in. CH, -11.70 CC |
| Ringset Included |
Yes |
| Engine |
EJ SERIES |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dish |
| Piston Material |
2618 |
| Add-On |
905-042-CT |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
905-2250-18-51S |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Subaru |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
