As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Fiat 146A |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Fiat, 146A, 3.209 in. Bore, 7.80:1, Flat Top, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.209 Bore, 1.311 CD, 0.866 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Fiat 146A 1.3L, 81.50 Bore, Flat, Set of 4 |
| Wrist Pin Wall Thickness |
0.150 |
| Make |
FIAT |
| Wrist Pin Length |
2.250 |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Head Type |
Flat |
| Wrist Pin Outer Diameter |
0.866 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
81.50 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Top Compression Ring Thickness |
0.0400 |
| Title |
JE Pistons - Fiat, 146A, 81.50 mm Bore, Piston Kit |
| Piston Quantity |
4 |
| Product Market |
European |
| Ringset Included |
Yes |
| Compression Height |
1.311 |
| Piston Average Weight |
296 |
| Engine - Web |
146A |
| Second Compression Ring Thickness |
0.0480 |
| Piston Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3209 |
| Engine |
146A |
| Prop 65 Yes/No |
Yes |
| Add-On |
866-063-MW |
| Cylinder Head |
146A |
| Piston Volume |
-6.40 |
| Title - Web |
JE Pistons Fiat 146A Piston Kit - 81.50 mm Bore - 1.311 in. CH, -6.40 CC |
| Add-On |
866-2250-15-51C |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Fiat |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Material |
2618 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
