As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Audi 2.7L S4 TT |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.228 Bore, 1.210 CD, 0.827 Pin, Set of 6. |
| Description_EXT |
JE, Audi, 2.7L S4 TT, 3.228 in. Bore, 9.00:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Audi 2.7L, 82.00 Bore, Dish, Set of 6 |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Piston Pin Outside Diameter |
0.827 |
| Wrist Pin Outer Diameter |
0.827 |
| Forging Type |
Round |
| Make |
AUDI |
| Piston Pin Material |
5115 |
| Piston Series |
JE Pistons |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Piston Quantity |
6 |
| Engine - Web |
2.7L S4 TT |
| Add-On |
JG1001-3228 |
| Industry |
Automotive |
| Compression Height |
1.210 |
| Piston Average Weight |
304 |
| Title |
JE Pistons - Audi, 2.7L S4 TT, 82.00 mm Bore, Piston Kit |
| Add-On |
827-2250-15-51C |
| Bore Diameter |
82.00 |
| Piston Pin Length |
2.250 |
| Top Compression Ring Thickness |
0.0400 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Product Market |
European |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
827-063-MW |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Cylinder Head |
2.7L TT 5V |
| Engine |
2.7L S4 TT |
| Piston Volume |
-4.50 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Audi 2.7L S4 TT Piston Kit - 82.00 mm Bore - 1.210 in. CH, -4.50 CC |
| Product Type |
Engine Piston Kit |
| Piston Material |
2618 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Audi |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
