As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 2JZ-GTE/2JZ-GE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.425 Bore, 1.338 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, Toyota, 2JZ-GTE, 3.425 in. Bore, 9.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Toyota 2JZ-GE/2JZ-GTE, 87.00 Bore, Dish, Set of 6 |
| Product Market |
Sport Compact |
| Industry |
Automotive |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
JG1001-3425 |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
866-063-MW |
| Add-On |
866-2250-15-51C |
| Title |
JE Pistons - Toyota, 2JZ-GTE, 87.00 mm Bore, Piston Kit |
| Title - Web |
JE Pistons Toyota 2JZ-GTE Piston Kit - 87.00 mm Bore - 1.338 in. CH, -8.90 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Compression Height |
1.338 |
| Piston Volume |
-8.90 |
| Piston Average Weight |
337 |
| Bore Diameter |
87.00 |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston Kit |
| Piston Quantity |
6 |
| Piston Material |
2618 |
| Cylinder Head |
2JZ-GTE |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Engine - Web |
2JZ-GTE |
| Make |
TOYOTA |
| Piston Pin Wall Thickness |
0.150 |
| Engine |
2JZ-GTE |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Piston Pin Length |
2.250 |
| Forging Type |
FSR |
| Make - Web |
Toyota |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Outer Diameter |
0.866 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
