As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Renault F7R WILL |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.268 Bore, 1.208 CD, 0.827 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Renault, F7R, 3.268 in. Bore, 12.50:1, Dome, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Renault F7R WILL, 83.00 Bore, Dome, Set of 4 |
| Forging Type |
FSR |
| Make |
RENAULT |
| Title |
JE Pistons - Renault, F7R, 83.00 mm Bore, Piston Kit |
| Piston Head Type |
Dome |
| Bore Diameter |
83.00 |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.827 |
| Prop 65 Yes/No |
Yes |
| Piston Quantity |
4 |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Out of Stock Message |
Call for Availability |
| Piston Volume |
4.50 |
| Product Market |
European |
| Product Type |
Engine Piston Kit |
| Piston Average Weight |
316 |
| Compression Height |
1.208 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Series |
JE Pistons |
| Piston Pin Outside Diameter |
0.827 |
| Make - Web |
Renault |
| Ring Set Included |
Yes |
| Engine - Web |
F7R |
| Wrist Pin Length |
2.250 |
| Add-On |
JG1001-3268 |
| Second Compression Ring Thickness |
0.0480 |
| Engine |
F7R |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
Yes |
| Cylinder Head |
F7R |
| Piston Pin Length |
2.250 |
| Add-On |
827-050-MW |
| Title - Web |
JE Pistons Renault F7R Piston Kit - 83.00 mm Bore - 1.208 in. CH, 4.50 CC |
| Add-On |
827-2250-15-51C |
| Piston Material |
2618 |
| Industry |
Automotive |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
