As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
BMW M3 S50B32 EURO |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.415 Bore, 1.271 CD, 0.827 Pin, Set of 6. |
| Description_EXT |
JE, BMW, S50B32 Euro, 3.415 in. Bore, 12.50:1, Dome, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
BMW S50B32 3.2L, 86.75 Bore, Dome, Set of 6 |
| Piston Head Type |
Dome |
| Piston Pin Outside Diameter |
0.827 |
| Forging Type |
Round |
| Make |
BMW |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Engine |
S50B32 EURO |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.827 |
| Engine - Web |
S50B32 Euro |
| Compression Height |
1.271 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0400 |
| Ringset Included |
Yes |
| Bore Diameter |
86.75 |
| Product Market |
European |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Title |
JE Pistons - BMW, S50B32 Euro, 86.75 mm Bore, Piston Kit |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Material |
2618 |
| Add-On |
JG1001-3425 |
| Second Compression Ring Thickness |
0.0480 |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Add-On |
827-2500-15-51C |
| Piston Pin Length |
2.500 |
| Piston Quantity |
6 |
| Piston Volume |
-5.40 |
| Out of Stock Message |
Call for Availability |
| Add-On |
827-063-MW |
| Product Type |
Engine Piston Kit |
| Title - Web |
JE Pistons BMW S50B32 Euro Piston Kit - 86.75 mm Bore - 1.271 in. CH, -5.40 CC |
| Cylinder Head |
S50B32 EURO |
| Wrist Pin Length |
2.500 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Make - Web |
BMW |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
7.0000 |
