As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K20/K24 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.465 Bore, 1.176 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, Acura, K Series, 3.465 in. Bore, 11.50:1, Dome, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda K20/K24, 88.00 Bore, Dome, Set of 4 |
| Make |
ACURA |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Ringset Included |
Yes |
| Compression Height |
1.176 |
| Piston Head Type |
Dome |
| Piston Average Weight |
336 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
88.00 |
| Oil Ring Thickness |
0.111 |
| Top Compression Ring Thickness |
0.0400 |
| Engine - Web |
K Series |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Piston Series |
JE Pistons |
| Piston Volume |
0.80 |
| Add-On |
JG1001-3465 |
| Industry |
Automotive |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
866-063-MW |
| Product Type |
Engine Piston Kit |
| Title |
JE Pistons - Acura, K Series, 88.00 mm Bore, Piston Kit |
| Add-On |
866-2250-15-51C |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Piston Quantity |
4 |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.866 |
| Piston Material |
2618 |
| Cylinder Head |
K20 |
| Title - Web |
JE Pistons Acura K Series Piston Kit - 88.00 mm Bore - 1.176 in. CH, 0.80 CC |
| Engine |
K Series |
| Second Compression Ring Thickness |
0.0480 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Acura |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
