As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda B18C1 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.189 Bore, 1.181 CD, 0.827 Pin, Set of 4. |
| Description_EXT |
JE, Honda, B Series, 3.189 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Honda B18C1, 81.00 Bore, Dish, Set of 4 |
| Make |
HONDA |
| Forging Type |
FSR |
| Compression Height |
1.181 |
| Piston Quantity |
4 |
| Piston Pin Material |
5115 |
| Title |
JE Pistons - Honda, B Series, 81.00 mm Bore, Piston Kit |
| Product Market |
Sport Compact |
| Wrist Pin Outer Diameter |
0.827 |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.827 |
| Piston Series |
JE Pistons |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Piston Average Weight |
277 |
| Bore Diameter |
81.00 |
| Piston Material |
2618 |
| Piston Volume |
-7.60 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0400 |
| Engine - Web |
B Series |
| Prop 65 Yes/No |
Yes |
| Piston Head Type |
Dish |
| Ringset Included |
Yes |
| Engine |
B Series |
| Second Compression Ring Thickness |
0.0480 |
| Title - Web |
JE Pistons Honda B Series Piston Kit - 81.00 mm Bore - 1.181 in. CH, -7.60 CC |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
827-2250-15-51C |
| Add-On |
827-063-MW |
| Cylinder Head |
B18C |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3189 |
| Piston Pin Length |
2.250 |
| Industry |
Automotive |
| Make - Web |
Honda |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
