As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan CA18DET |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.307 Bore, 1.181 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Nissan, CA18DET, 3.307 in. Bore, 8.50:1, Flat Top, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan CA18DET, 84.00 Bore, Flat, Set of 4 |
| Wrist Pin Length |
2.250 |
| Piston Volume |
0.00 |
| Product Type |
Engine Piston Kit |
| Engine |
CA18DET |
| Ring Set Included |
Yes |
| Add-On |
787-2250-18-51C |
| Add-On |
787-050-MW |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Add-On |
JG1001-3307 |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
CA18DET |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Nissan |
| Engine Type |
ICE |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Quantity |
4 |
| Piston Pin Material |
5115 |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
Sport Compact |
| Oil Ring Thickness |
0.111 |
| Piston Material |
2618 |
| Make |
NISSAN |
| Ringset Included |
Yes |
| Piston Head Type |
Flat |
| Title - Web |
JE Pistons Nissan CA18DET Piston Kit - 84.00 mm Bore - 1.181 in. CH, 0.00 CC |
| Forging Type |
FSR |
| Piston Pin Wall Thickness |
0.180 |
| Piston Average Weight |
300 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.787 |
| Wrist Pin Wall Thickness |
0.180 |
| Bore Diameter |
84.00 |
| Piston Series |
JE Pistons |
| Compression Height |
1.181 |
| Title |
JE Pistons - Nissan, CA18DET, 84.00 mm Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.787 |
| Engine - Web |
CA18DET |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
