As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Hyundai 2.0T Theta Genesis |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.406 Bore, 1.181 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, Hyundai, 2.0T Theta Genisis, 3.405 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Hyundai 2.0T Theta Genesis, 86.50 Bore, Dish, Set of 4 |
| Piston Series |
JE Pistons |
| Make - Web |
Hyundai |
| Add-On |
JG1001-3405 |
| Add-On |
866-2250-15-51C |
| Add-On |
866-063-MW |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Dish |
| Title - Web |
JE Pistons Hyundai 2.0T Theta Genesis Piston Kit - 86.50 mm Bore - 1.181 in. CH, -6.20 CC |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Oil Ring Thickness |
0.111 |
| Compression Height |
1.181 |
| Piston Pin Material |
5115 |
| Top Compression Ring Thickness |
0.0400 |
| Cylinder Head |
THETA I4 |
| Prop 65 (C, R or CR) |
CR |
| Make |
HYUNDAI |
| Piston Pin Wall Thickness |
0.150 |
| Engine |
2.0T THETA GENISIS |
| Title |
JE Pistons - Hyundai, 2.0T Theta Genesis, 86.50 mm Bore, Piston Kit |
| Forging Type |
FSR |
| Piston Pin Outside Diameter |
0.866 |
| Product Market |
Sport Compact |
| Piston Material |
2618 |
| Industry |
Automotive |
| Piston Quantity |
4 |
| Piston Volume |
-6.20 |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Engine - Web |
2.0T Theta Genesis |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Average Weight |
305 |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
86.50 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
