As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Hyundai 2.0T Theta Genesis |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.386 Bore, 1.181 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, Hyundai, 2.0T Theta Genisis, 3.386 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Hyundai 2.0T Theta Genesis, 86.00 Bore, Dish, Set of 4 |
| Product Market |
Sport Compact |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Bore Diameter |
86.00 |
| Top Compression Ring Thickness |
0.0400 |
| Ring Set Included |
Yes |
| Piston Volume |
-5.50 |
| Cylinder Head |
THETA I4 |
| Piston Quantity |
4 |
| Piston Average Weight |
304 |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.250 |
| Engine - Web |
2.0T Theta Genesis |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
JG1001-3386 |
| Ringset Included |
Yes |
| Add-On |
866-063-MW |
| Title - Web |
JE Pistons Hyundai 2.0T Theta Genesis Piston Kit - 86.00 mm Bore - 1.181 in. CH, -5.50 CC |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dish |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Add-On |
866-2250-15-51C |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Hyundai |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.150 |
| Engine Type |
ICE |
| Piston Pin Length |
2.250 |
| Title |
JE Pistons - Hyundai, 2.0T Theta Genesis, 86.00 mm Bore, Piston Kit |
| Oil Ring Thickness |
0.111 |
| Compression Height |
1.181 |
| Forging Type |
FSR |
| Engine |
2.0T Theta Genesis |
| Piston Series |
JE Pistons |
| Make |
HYUNDAI |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
