As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T FSI 04-08 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.268 Bore, 1.155 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T FSI - 04-08 - 20mm Pin, 3.267 in. Bore, 10.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.00 Bore, Dish, Set of 4 |
| Forging Type |
Round |
| Bore Diameter |
83.00 |
| Ringset Included |
Yes |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Outside Diameter |
0.787 |
| Title |
JE Pistons - Volkswagen, 2.0T FSI, 83.00 mm Bore, Piston Kit |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Compression Height |
1.155 |
| Engine - Web |
2.0T FSI |
| Wrist Pin Outer Diameter |
0.787 |
| Add-On |
787-2250-18-51C |
| Product Market |
European |
| Piston Volume |
-0.50 |
| Add-On |
787-050-MW |
| Cylinder Head |
2.0LGOLF FSI |
| Product Type |
Engine Piston Kit |
| Piston Quantity |
4 |
| Industry |
Automotive |
| Piston Head Type |
Dish |
| Make |
VOLKSWAGEN |
| Add-On |
JG1001-3268 |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Average Weight |
299 |
| Engine Detail |
2.0T FSI 04-08 20 mm Pin |
| Make - Web |
Volkswagen |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Pin Length |
2.250 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Out of Stock Message |
Call for Availability |
| Engine |
2.0T FSI 04-08 20 mm Pin |
| Piston Material |
2618 |
| Title - Web |
JE Pistons Volkswagen 2.0T FSI Piston Kit - 83.00 mm Bore - 1.155 in. CH, -0.50 CC |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
