As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 2.0L Zetec |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.346 Bore, 1.171 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Ford, 2.0L ZETEC, 3.346 in. Bore, 11.00:1, Dome, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford Zetec 2.0L, 85.00 Bore, Dome, Set of 4 |
| Bore Diameter |
85.00 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Series |
JE Pistons |
| Product Market |
Sport Compact |
| Top Compression Ring Thickness |
0.0400 |
| Piston Average Weight |
319 |
| Ringset Included |
Yes |
| Wrist Pin Wall Thickness |
0.180 |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Title |
JE Pistons - Ford, 2.0L ZETEC, 85.00 mm Bore, Piston Kit |
| Piston Head Type |
Dome |
| Make |
FORD |
| Piston Quantity |
4 |
| Piston Pin Outside Diameter |
0.787 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.787 |
| Engine - Web |
2.0L ZETEC |
| Industry |
Automotive |
| Compression Height |
1.171 |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
2.0L ZETEC |
| Piston Material |
2618 |
| Add-On |
787-050-MW |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
787-2250-18-51C |
| Piston Volume |
5.00 |
| Engine |
2.0L ZETEC |
| Add-On |
JG1001-3346 |
| Out of Stock Message |
Call for Availability |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Piston Pin Length |
2.250 |
| Title - Web |
JE Pistons Ford 2.0L ZETEC Piston Kit - 85.00 mm Bore - 1.171 in. CH, 5.00 CC |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
