As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K20 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.406 Bore, 1.176 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, Acura, K Series, 3.405 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda K20, 86.50 Bore, Dish, Set of 4 |
| Product Market |
Sport Compact |
| Top Compression Ring Thickness |
0.0400 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
86.50 |
| Compression Height |
1.176 |
| Piston Average Weight |
308 |
| Wrist Pin Wall Thickness |
0.150 |
| Title |
JE Pistons - Acura, K Series, 86.50 mm Bore, Piston Kit |
| Piston Material |
2618 |
| Make |
ACURA |
| Piston Pin Material |
5115 |
| Piston Volume |
-5.30 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Cylinder Head |
K20 |
| Engine - Web |
K Series |
| Ring Set Included |
Yes |
| Product Type |
Engine Piston Kit |
| Add-On |
866-063-MW |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
0.866 |
| Ringset Included |
Yes |
| Add-On |
JG1001-3405 |
| Add-On |
866-2250-15-51C |
| Piston Quantity |
4 |
| Industry |
Automotive |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Out of Stock Message |
Call for Availability |
| Engine |
K Series |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Dish |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Forging Type |
FSR |
| Title - Web |
JE Pistons Acura K Series Piston Kit - 86.50 mm Bore - 1.176 in. CH, -5.30 CC |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Acura |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
