As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 3.2L VR6 R32 24V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.327 Bore, 1.593 CD, 0.787 Pin, Set of 6. |
| Description_EXT |
JE, VW, 3.2L VR6 24V, 3.327 in. Bore, 8.50:1, Flat Top, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Volkswagen 3.2L R32 24V VR6, 84.50 Bore, Flat, Set of 6 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Piston Pin Length |
2.250 |
| Product Type |
Engine Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Average Weight |
334 |
| Wrist Pin Length |
2.250 |
| Industry |
Automotive |
| Piston Quantity |
6 |
| Piston Volume |
-27.80 |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Add-On |
787-2250-18-51C |
| Second Compression Ring Thickness |
0.0480 |
| Cylinder Head |
R32 VR6 |
| Add-On |
787-050-MW |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Add-On |
JG1001-3327 |
| Title - Web |
JE Pistons Volkswagen 3.2L VR6 24V Piston Kit - 84.50 mm Bore - 1.593 in. CH, -27.80 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Volkswagen |
| Piston Pin Outside Diameter |
0.787 |
| Piston Head Type |
Flat |
| Title |
JE Pistons - Volkswagen, 3.2L VR6 24V, 84.50 mm Bore, Piston Kit |
| Piston Pin Material |
5115 |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
European |
| Piston Pin Wall Thickness |
0.180 |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Forging Type |
Round |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Bore Diameter |
84.50 |
| Engine |
3.2L VR6 24V |
| Make |
VOLKSWAGEN |
| Compression Height |
1.593 |
| Wrist Pin Wall Thickness |
0.180 |
| Engine - Web |
3.2L VR6 24V |
| Wrist Pin Outer Diameter |
0.787 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
