As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Small Block NASCAR Canada |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.040 in. Bore, 1.550 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 4.040 Bore, 1.550 CD, 0.927 Pin, Set of 8. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 350, 4.040 Bore, Dish, Set of 8 |
| Product Market |
Domestic |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Series |
JE Pistons |
| Forging Type |
Round |
| Piston Average Weight |
494 |
| Bore Diameter |
4.040 |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.188 |
| Ringset Included |
No |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Title |
JE Pistons - Chevrolet, Small Block, 4.040 in. Bore, Piston Kit |
| Compression Height |
1.550 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Quantity |
8 |
| Piston Pin Outside Diameter |
0.927 |
| Make |
CHEVROLET |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Material |
2618 |
| Piston Volume |
-11.00 |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
927-042-CS |
| Product Type |
Engine Piston Kit |
| Piston Pin Length |
2.500 |
| Add-On |
J10008-4040-5 |
| Cylinder Head |
STD CHEVROLET 23 DEG |
| Industry |
Automotive |
| Add-On |
927-2500-15-51S |
| Engine |
Small Block |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Chevrolet Small Block Piston Kit - 4.040 in. Bore - 1.550 in. CH, -11.00 CC |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Wrist Pin Length |
2.500 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
