As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 427 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.350 in. Bore, 1.270 CD, Dome, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.350 Bore, 1.270 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 427, 4.350 Bore, Dome, Set of 8 |
| Title |
JE Pistons - Chevrolet, Big Block, 4.350 in. Bore, Piston Kit |
| Piston Average Weight |
585 |
| Bore Diameter |
4.350 |
| Product Type |
Engine Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Compression Height |
1.270 |
| Wrist Pin Length |
2.930 |
| Engine - Web |
Big Block |
| Product Market |
Domestic |
| Piston Material |
2618 |
| Cylinder Head |
OPEN CHAMBER |
| Top Compression Ring Thickness |
0.0640 |
| Piston Quantity |
8 |
| Ring Set Included |
No |
| Piston Volume |
43.00 |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
0.990 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
990-042-CS |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.350 in. Bore - 1.270 in. CH, 43.00 CC |
| Piston Pin Length |
2.930 |
| Forging Type |
Round |
| Add-On |
J10008-4350-5 |
| Oil Ring Thickness |
0.218 |
| Make |
CHEVROLET |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dome |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Engine |
Big Block |
| Add-On |
990-2930-15-51S |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
No |
| Make - Web |
Chevrolet |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
