As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 427 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.375 Bore, 1.120 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.375 in. Bore, 1.120 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 427, 4.375 Bore, Dome, Set of 8 |
| Piston Series |
JE Pistons |
| Piston Pin Outside Diameter |
0.990 |
| Make |
CHEVROLET |
| Ringset Included |
No |
| Piston Head Type |
Dome |
| Engine |
Big Block |
| Piston Pin Length |
2.930 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Title |
JE Pistons - Chevrolet, Big Block, 4.375 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Forging Type |
Round |
| Compression Height |
1.120 |
| Oil Ring Thickness |
0.218 |
| Piston Pin Wall Thickness |
0.150 |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 Yes/No |
Yes |
| Piston Average Weight |
556 |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
4.375 |
| Piston Volume |
44.00 |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.375 in. Bore - 1.120 in. CH, 44.00 CC |
| Second Compression Ring Thickness |
0.0640 |
| Piston Material |
2618 |
| Piston Quantity |
8 |
| Top Compression Ring Thickness |
0.0640 |
| Cylinder Head |
OPEN CHAMBER |
| Make - Web |
Chevrolet |
| Wrist Pin Length |
2.930 |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.990 |
| Add-On |
990-042-CS |
| Add-On |
J10008-4375-5 |
| Add-On |
990-2930-15-51S |
| Industry |
Automotive |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
