As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda F20C1 S2000 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.425 Bore, 1.181 CD, 0.905 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Honda, F Series, 3.425 in. Bore, 11.50:1, Dome, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Honda F20C, 87.00 Bore, Dome, Set of 4 |
| Engine - Web |
F Series |
| Piston Pin Wall Thickness |
0.150 |
| Piston Volume |
5.50 |
| Piston Quantity |
4 |
| Product Type |
Engine Piston Kit |
| Piston Pin Outside Diameter |
0.905 |
| Piston Pin Material |
5115 |
| Forging Type |
Round |
| Make |
HONDA |
| Oil Ring Thickness |
0.111 |
| Title |
JE Pistons - Honda, F Series, 87.00 mm Bore, Piston Kit |
| Wrist Pin Length |
2.250 |
| Compression Height |
1.181 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Engine Type |
ICE |
| Bore Diameter |
87.00 |
| Piston Series |
JE Pistons |
| Piston Head Type |
Dome |
| Piston Average Weight |
320 |
| Add-On |
905-2250-15-51C |
| Second Compression Ring Thickness |
0.0480 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Product Market |
Sport Compact |
| Cylinder Head |
F20C1 |
| Ringset Included |
Yes |
| Out of Stock Message |
Call for Availability |
| Engine |
F SERIES |
| Title - Web |
JE Pistons Honda F Series Piston Kit - 87.00 mm Bore - 1.181 in. CH, 5.50 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
JG1001-3425 |
| Top Compression Ring Thickness |
0.0400 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Add-On |
905-073-MW |
| Make - Web |
Honda |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.905 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
