As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 502 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.600 Bore, 1.060 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.600 in. Bore, 1.060 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Chevrolet 502, 4.600 Bore, Dome, Set of 8 |
| Second Compression Ring Thickness |
0.0440 |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.600 in. Bore - 1.060 in. CH, 43.00 CC |
| Engine |
Big Block |
| Piston Series |
JE Pistons |
| Make - Web |
Chevrolet |
| Add-On |
990-2930-18-51S |
| Add-On |
JG7708-4600-5 |
| Add-On |
990-042-CS |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Head Type |
Dome |
| Engine Type |
ICE |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
No |
| Prop 65 Yes/No |
Yes |
| Bore Diameter |
4.600 |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0435 |
| Cylinder Head |
OPEN CHAMBER |
| Title |
JE Pistons - Chevrolet, Big Block, 4.600 in. Bore, Piston Kit |
| Piston Volume |
43.00 |
| Oil Ring Thickness |
0.149 |
| Piston Pin Wall Thickness |
0.180 |
| Forging Type |
Round |
| Piston Pin Length |
2.930 |
| Piston Average Weight |
565 |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Compression Height |
1.060 |
| Industry |
Automotive |
| Product Market |
Domestic |
| Piston Pin Outside Diameter |
0.990 |
| Piston Quantity |
8 |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Make |
CHEVROLET |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Length |
2.930 |
| Wrist Pin Outer Diameter |
0.990 |
| Engine - Web |
Big Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
