Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.000 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.000 in. Bore, 1.125 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 350, 4.000 Bore, Dome, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Piston Average Weight |
414 |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0640 |
| Oil Ring Thickness |
0.218 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Series |
SRP |
| Make |
CHEVROLET |
| Piston Pin Outside Diameter |
0.927 |
| Bore Diameter |
4.000 |
| Compression Height |
1.125 |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Piston Material |
2618 |
| Product Market |
Domestic |
| Piston Volume |
7.00 |
| Product Type |
Engine Piston Kit |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Length |
2.750 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Prop 65 Yes/No |
Yes |
| Title |
SRP - Chevrolet, Small Block, 4.000 in. Bore, Piston Kit |
| Add-On |
S100S8-4000-5 |
| Industry |
Automotive |
| Add-On |
927-2750-15-51S |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.750 |
| Second Compression Ring Thickness |
0.0640 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Add-On |
927-042-CS |
| Forging Type |
FSR |
| Piston Head Type |
Dome |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.000 in. Bore - 1.125 in. CH, 7.00 CC |
| Make - Web |
Chevrolet |
| Engine |
Small Block |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
