Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.375 Bore, 2.062 CD, 1.094 Pin, Set of 8. |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.375 in. Bore, 2.062 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.375 Bore, Flat, Set of 8 |
| Engine - Web |
Big Block |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Material |
4032 |
| Bore Diameter |
4.375 |
| Industry |
Automotive |
| Piston Average Weight |
714 |
| Title |
SRP - Chrysler, Big Block, 4.375 in. Bore, Piston Kit |
| Product Market |
Domestic |
| Cylinder Head |
440 WEDGE |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.375 in. Bore - 2.062 in. CH, -6.00 CC |
| Out of Stock Message |
Call for Availability |
| Product Type |
Engine Piston Kit |
| Piston Pin Outside Diameter |
1.094 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0640 |
| Piston Volume |
-6.00 |
| Top Compression Ring Thickness |
0.0640 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.930 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chrysler |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.188 |
| Add-On |
S100S8-4375-5 |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Piston Head Type |
Flat |
| Add-On |
094-2930-15-51S |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
No |
| Engine |
Big Block |
| Prop 65 (C, R or CR) |
CR |
| Make |
CHRYSLER |
| Add-On |
094-037-CS |
| Wrist Pin Outer Diameter |
1.094 |
| Ring Set Included |
No |
| Compression Height |
2.062 |
| Piston Pin Length |
2.930 |
| Piston Series |
SRP |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
