Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Dome, 4.500 Bore, 1.270 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.500 in. Bore, 1.270 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 454, 4.500 Bore, Dome, Set of 8 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.990 |
| Bore Diameter |
4.500 |
| Piston Head Type |
Dome |
| Oil Ring Thickness |
0.218 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Pin Outside Diameter |
0.990 |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Piston Average Weight |
601 |
| Ring Set Included |
No |
| Add-On |
990-2930-15-51S |
| Out of Stock Message |
Call for Availability |
| Piston Series |
SRP |
| Piston Volume |
10.00 |
| Compression Height |
1.270 |
| Add-On |
S100S8-4500-5 |
| Add-On |
990-042-CS |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Product Type |
Engine Piston Kit |
| Make |
CHEVROLET |
| Piston Pin Length |
2.930 |
| Engine |
Big Block |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Engine - Web |
Big Block |
| Cylinder Head |
OPEN CHAMBER |
| Ringset Included |
No |
| Title |
SRP - Chevrolet, Big Block, 4.500 in. Bore, Piston Kit |
| Second Compression Ring Thickness |
0.0640 |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.500 in. Bore - 1.270 in. CH, 10.00 CC |
| Piston Material |
4032 |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Length |
2.930 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
