As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan RB26DT R32-34 Skyline |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Nissan, RB Series, 3.405 in. Bore, 8.50:1, Dome, 6 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.405 Bore, 1.185 CD, 0.827 Pin, Set of 6. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan RB26DT, 86.50 Bore, Dome, Set of 6 |
| Industry |
Automotive |
| Title |
JE Pistons - Nissan, RB Series, 86.50 mm Bore, Piston Kit |
| Compression Height |
1.185 |
| Piston Average Weight |
355 |
| Cylinder Head |
RB26DETT |
| Piston Material |
2618 |
| Engine - Web |
RB Series |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0480 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Bore Diameter |
86.50 |
| Product Type |
Engine Piston Kit |
| Product Market |
Sport Compact |
| Piston Volume |
15.30 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
Yes |
| Make |
NISSAN |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.827 |
| Add-On |
827-063-MW |
| Add-On |
JC2104-3406 |
| Prop 65 Yes/No |
Yes |
| Add-On |
827-2250-15-51C |
| Piston Quantity |
6 |
| Wrist Pin Outer Diameter |
0.827 |
| Wrist Pin Length |
2.250 |
| Oil Ring Thickness |
0.119 |
| Forging Type |
Round |
| Ringset Included |
Yes |
| Second Compression Ring Thickness |
0.0600 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.250 |
| Title - Web |
JE Pistons Nissan RB Series Piston Kit - 86.50 mm Bore - 1.185 in. CH, 15.30 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Nissan |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Engine |
RB SERIES |
| Piston Head Type |
Dome |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
7.0000 |
