As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.560 Bore, 1.120 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.560 in. Bore, 1.120 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 454, 4.560 Bore, Dome, Set of 8 |
| Product Type |
Engine Piston Kit |
| Piston Quantity |
8 |
| Wrist Pin Length |
2.930 |
| Engine - Web |
Big Block |
| Title |
JE Pistons - Chevrolet, Big Block, 4.560 in. Bore, Piston Kit |
| Make |
CHEVROLET |
| Piston Volume |
13.00 |
| Oil Ring Thickness |
0.218 |
| Industry |
Automotive |
| Ring Set Included |
No |
| Piston Pin Material |
5115 |
| Forging Type |
Round |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Wall Thickness |
0.150 |
| Product Market |
Domestic |
| Piston Pin Outside Diameter |
0.990 |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
2618 |
| Piston Average Weight |
584 |
| Compression Height |
1.120 |
| Top Compression Ring Thickness |
0.0436 |
| Wrist Pin Outer Diameter |
0.990 |
| Piston Pin Length |
2.930 |
| Ringset Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 Yes/No |
Yes |
| Add-On |
990-042-CS |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Add-On |
J20008-4560-5 |
| Add-On |
990-2930-15-51S |
| Engine Type |
ICE |
| Piston Head Type |
Dome |
| Bore Diameter |
4.560 |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.560 in. Bore - 1.120 in. CH, 13.00 CC |
| Engine |
Big Block |
| Cylinder Head |
BIG CHIEF |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
JE Pistons |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
