Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Big Block 460 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.440 Bore, 1.770 CD, 1.040 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Big Block Ford, 4.440 in. Bore, 1.760 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 460, 4.440 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Engine |
Big Block |
| Piston Pin Material |
5115 |
| Piston Series |
SRP |
| Ringset Included |
No |
| Piston Pin Length |
2.930 |
| Engine Type |
ICE |
| Compression Height |
1.770 |
| Title |
SRP - Ford, Big Block, 4.440 in. Bore, Piston Kit |
| Forging Type |
FSR |
| Piston Head Type |
Flat |
| Piston Pin Wall Thickness |
0.180 |
| Make |
FORD |
| Wrist Pin Outer Diameter |
1.040 |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Volume |
-3.00 |
| Add-On |
J100F8-4440-5 |
| Bore Diameter |
4.440 |
| Title - Web |
SRP Ford Big Block Piston Kit - 4.440 in. Bore - 1.770 in. CH, -3.00 CC |
| Oil Ring Thickness |
0.188 |
| Cylinder Head |
SUPER COBRA JET |
| Top Compression Ring Thickness |
0.0640 |
| Product Market |
Domestic |
| Add-On |
040-2930-18-51S |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
1.040 |
| Second Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Add-On |
031-042-CS |
| Piston Average Weight |
682 |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Length |
2.930 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
No |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Material |
4032 |
| Out of Stock Message |
Call for Availability |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
