Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DES |
Piston Set, 2618, Dome, 4.155 Bore, 1.260 CD, 0.927 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.155 in. Bore, 1.260 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chevrolet 400, 4.155 Bore, Dome, Set of 8 |
| Compression Height |
1.260 |
| Title |
SRP - Chevrolet, Small Block, 4.155 in. Bore, Piston Kit |
| Piston Volume |
9.00 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Engine - Web |
Small Block |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Bore Diameter |
4.155 |
| Piston Material |
2618 |
| Product Market |
Domestic |
| Wrist Pin Wall Thickness |
0.150 |
| Add-On |
S100S8-4155-5 |
| Piston Average Weight |
495 |
| Industry |
Automotive |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0640 |
| Make |
CHEVROLET |
| Add-On |
927-2750-15-51S |
| Piston Pin Outside Diameter |
0.927 |
| Add-On |
927-042-CS |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Outer Diameter |
0.927 |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.155 in. Bore - 1.260 in. CH, 9.00 CC |
| Piston Pin Material |
5115 |
| Piston Series |
SRP |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dome |
| Ringset Included |
No |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0640 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Wrist Pin Length |
2.750 |
| Oil Ring Thickness |
0.188 |
| Engine Type |
ICE |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
