Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.350 Bore, 1.270 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.350 in. Bore, 1.270 CD, Dome, 8 Cyl. Piston Kit |
| Description_TLE |
Chevrolet 454, 4.350 Bore, Dome, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Out of Stock Message |
Call for Availability |
| Product Type |
Engine Piston Kit |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.930 |
| Engine |
Big Block |
| Industry |
Automotive |
| Piston Volume |
43.00 |
| Add-On |
990-042-CS |
| Add-On |
S100S8-4350-5 |
| Second Compression Ring Thickness |
0.0640 |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.350 in. Bore - 1.270 in. CH, 43.00 CC |
| Add-On |
990-2930-15-51S |
| Piston Material |
2618 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Piston Average Weight |
619 |
| Engine Type |
ICE |
| Cylinder Head |
OPEN CHAMBER |
| Piston Pin Wall Thickness |
0.150 |
| Make |
CHEVROLET |
| Ringset Included |
No |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.218 |
| Piston Head Type |
Dome |
| Compression Height |
1.270 |
| Piston Pin Outside Diameter |
0.990 |
| Forging Type |
FSR |
| Piston Series |
SRP |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Length |
2.930 |
| Wrist Pin Wall Thickness |
0.150 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Title |
SRP - Chevrolet, Big Block, 4.350 in. Bore, Piston Kit |
| Product Market |
Domestic |
| Bore Diameter |
4.350 |
| Top Compression Ring Thickness |
0.0640 |
| Engine - Web |
Big Block |
| Ring Set Included |
No |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
