Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.310 Bore, 1.520 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.310 in. Bore, 1.520 CD, Dome, 8 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 454, 4.310 Bore, Dome, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Prop 65 (C, R or CR) |
CR |
| Make - Web |
Chevrolet |
| Piston Volume |
43.00 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.930 |
| Second Compression Ring Thickness |
0.0640 |
| Piston Pin Outside Diameter |
0.990 |
| Piston Material |
2618 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Top Compression Ring Thickness |
0.0640 |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.310 in. Bore - 1.520 in. CH, 43.00 CC |
| Bore Diameter |
4.310 |
| Cylinder Head |
OPEN CHAMBER |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Add-On |
990-042-CS |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Piston Average Weight |
655 |
| Add-On |
S100S8-4310-5 |
| Add-On |
990-2930-15-51S |
| Industry |
Automotive |
| Piston Head Type |
Dome |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Product Market |
Domestic |
| Engine |
Big Block |
| Piston Pin Length |
2.930 |
| Title |
SRP - Chevrolet, Big Block, 4.310 in. Bore, Piston Kit |
| Make |
CHEVROLET |
| Ringset Included |
No |
| Oil Ring Thickness |
0.188 |
| Forging Type |
FSR |
| Compression Height |
1.520 |
| Piston Series |
SRP |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.990 |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
