Edelbrock 71413 Black Cross- Ram LS3 Intake Manifold

2 sold in last 8 days
Edelbrock
ds_BDVJ_71413
Engine Intake Manifold
$2,361.85
customers are viewing this product
Edelbrock 7181 RPM 351W 9.5 Deck Intake Manifold
Edelbrock 7181 RPM 351W 9.5 Deck Intake Manifold
$617.78
Edelbrock 7180 Victor 2 5.0L Coyote Intake Manifold
Edelbrock 7180 Victor 2 5.0L Coyote Intake Manifold
$2,377.13
Edelbrock 71413 Black Cross- Ram LS3 Intake Manifold
Details

Edelbrock part #71413 LS3 Cross-Ram intake manifold is designed for Gen IV engines with LS3, L92 and L76 rectangular port cylinder heads. The Cross-Ram LS3 is ideal for anybody looking to combine great looks and outstanding performance between 1,500 - 7,000 rpm. The unique dual-plenum design features 13" long runners with flanges that will accept two, 90mm GM LS3 throttle bodies. The unique cross-ram dual-plenum design is ideal for twin turbo applications. When matched with high flowing air filters and inlet tubes, the dual-plenum system gives neck-snapping performance with plenty of options for engine builders and tuners.

Specifications:

Description_ABR Intake Mnfld
Description_ASM Chevrolet:Small-Block Gen IV L76:364 (6.0L)
Description_ASM Chevrolet:Small-Block Gen IV L77:364 (6.0L)
Description_ASM Chevrolet:Small-Block Gen IV L92:376 (6.2L)
Description_ASM Chevrolet:Small-Block Gen IV L94:376 (6.2L)
Description_ASM Chevrolet:Small-Block Gen IV L99:376 (6.2L)
Description_ASM Chevrolet:Small-Block Gen IV L9H:376 (6.2L)
Description_ASM Chevrolet:Small-Block Gen IV LS3:376 (6.2L)
Description_DEF Engine Intake Manifold
Description_EXT Edelbrock Black Cross- Ram LS3 Rect Ports Intake Manifold GM LS Engines
Description_INV Black Cross- Ram LS3 Intake Manifold
Description_MKT Edelbrock part #71413 LS3 Cross-Ram intake manifold is designed for Gen IV engines with LS3, L92 and L76 rectangular port cylinder heads. The Cross-Ram LS3 is ideal for anybody looking to combine great looks and outstanding performance between 1,500 - 7,000 rpm. The unique dual-plenum design features 13" long runners with flanges that will accept two, 90mm GM LS3 throttle bodies. The unique cross-ram dual-plenum design is ideal for twin turbo applications. When matched with high flowing air filters and inlet tubes, the dual-plenum system gives neck-snapping performance with plenty of options for engine builders and tuners.
Description_TRA Throttle Body Recommendations: 2x GM LS# 90mm
Description_TRA Fuel Rail Recommendations: Use Edelbrock fuel rail kit #3654.
Description_TRA Uses LS3/L76 style individual port o-ring seals GM PN19256623 or Edelbrock #7395.
Description_TRA Plenum gaskets use Edelbrock #7271
Description_TRA Manifold height: A-9.35", B-8.01", C-17.50", D-2.65" E-0 degree vertical x 5 degree inward
Description_TRA Port exit dimensions: 1.19" x 2.48"
Description_TRA Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.
Description_TRA Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Description_LAB Cross-Ram Small Block Chevy LS3 Black Intake Manifold
Basic Operating RPM Range 1500-7000
CNC Ported No
Center Maximum Height 9.350
Gasket Or Seal Included No
EGR Port No
Grade Type Performance
Flange Type Cross-Ram
Finish Black Powder Coated
Front Maximum Height 9.350
Material Aluminum
Rear Maximum Height 8.010
Single Or Dual Plane Type Single
Series Cross-Ram LS3
RGL WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Vehicle Model Chevrolet
Length 13.0000
Width 15.0000
Height 24.0000
Weight 42.0000
