In 1974 With The Rising Popularity Of Power Adders Such As Nitrous,Superchargers And Turbochargers, Mcleod Recognized The Need For A Clutch Assembly That Was Street Friendly, Yet Still Capable Of Handling Up To 1,200 Horsepower, Thus The Street Twin Was Born! This Series Of Mcleod Clutch Kit Is Intended For High Horsepower Street Enthusiast. Whether It'S Nos,Supercharger,Turbocharger Or A Big Inch Mountain Motor The "Original Street Twin" Can Handle It. Go With The Innovator Not The Imitator Mcleod Racing!
Specifications:
| Description_ASM |
Ford: Mustang 00 - 00 5.4 L Engine, Ford: Mustang 96 - 04 4.6 L Engine |
| Description_DEF |
Transmission Clutch Kit |
| Description_DES |
Original Street Twin: Aluminum: Ford: 1996-04 4.6L: 8 Bolt Crank: 1-1/8x26: 164T |
| Description_EXT |
Original Street Twin: Aluminum: Ford: 1996-04 4.6L: 8 Bolt Crank: 1-1/8x26: 164T: Cable Linkage: Ceramic Discs |
| Description_FAB |
McLeod Racing is the leader in twin disc clutch applications. We offer them in several different configurations to meet your needs. Give us a call 714-630-2764 to see what we can do for you! |
| Description_INV |
Clutch Kit |
| Description_MKT |
In 1974 With The Rising Popularity Of Power Adders Such As Nitrous,Superchargers And Turbochargers, Mcleod Recognized The Need For A Clutch Assembly That Was Street Friendly, Yet Still Capable Of Handling Up To 1,200 Horsepower, Thus The Street Twin Was Born! This Series Of Mcleod Clutch Kit Is Intended For High Horsepower Street Enthusiast. Whether It'S Nos,Supercharger,Turbocharger Or A Big Inch Mountain Motor The "Original Street Twin" Can Handle It. Go With The Innovator Not The Imitator Mcleod Racing! |
| Description_SHO |
Clutch Kit |
| Pilot Bushing Material |
N/A |
| Make |
Ford |
| Hardware Included |
Yes |
| Disc Diameter |
10.5In. |
| Flywheel Included |
Yes |
| Clutch Patterns |
10.5In. Street Twin Pattern |
| Disc Material |
Ceramic |
| Spline |
1-1/8 x 26 |
| Alignment Tool Included |
Yes |
| Number of Discs |
Double |
| Pilot Bushing Included |
No |
| Hub Style |
Solid |
| Clutch Usage |
Street |
| Throwout Bearing Style |
Cable Linkage |
| Pressure Plate Style |
Diaphragm |
| Throwout Bearing Included |
Yes |
| Horsepower Rating |
1500 |
| Engine Balance |
Neutral |
| Engine |
1996-2017 4.6L/5.0L/5.4L 8 Bolt Crank |
| Additional Counter Weight Kit Required |
No |
| Flywheel Material |
Aluminum |
| Disc Style |
Segmented Puck |
| Ring Gear |
164T |
| Length |
6.0000 |
| Width |
17.0000 |
| Height |
16.0000 |
| Weight |
45.0000 |
