In 1974 With The Rising Popularity Of Power Adders Such As Nitrous,Superchargers And Turbochargers, Mcleod Recognized The Need For A Clutch Assembly That Was Street Friendly, Yet Still Capable Of Handling Up To 1,200 Horsepower, Thus The Street Twin Was Born! This Series Of Mcleod Clutch Kit Is Intended For High Horsepower Street Enthusiast. Whether It'S Nos,Supercharger,Turbocharger Or A Big Inch Mountain Motor The "Original Street Twin" Can Handle It. Go With The Innovator Not The Imitator Mcleod Racing!
Specifications:
| Description_ASM |
Chevrolet: Camaro 86 - 92 5 L Engine, Pontiac: Firebird 87 - 92 5.7 L Engine, Chevrolet: Camaro 87 - 92 5.7 L Engine, Pontiac: Firebird 86 - 92 5 L Engine, Chevrolet: Corvette 86 - 88 5.7 L Engine |
| Description_DEF |
Transmission Clutch Kit |
| Description_DES |
Original Street Twin: Aluminum:Chevrolet:1986-99 SBC:153T:1-1/8x26:Ceramic Discs |
| Description_EXT |
Original Street Twin: Aluminum: Chevrolet: 1986-99 SBC: 153T: 1-1/8x26: Ceramic Discs |
| Description_INV |
Clutch Kit |
| Description_FAB |
McLeod Racing is the leader in twin disc clutch applications. We offer them in several different configurations to meet your needs. Give us a call 714-630-2764 to see what we can do for you! |
| Description_MKT |
In 1974 With The Rising Popularity Of Power Adders Such As Nitrous,Superchargers And Turbochargers, Mcleod Recognized The Need For A Clutch Assembly That Was Street Friendly, Yet Still Capable Of Handling Up To 1,200 Horsepower, Thus The Street Twin Was Born! This Series Of Mcleod Clutch Kit Is Intended For High Horsepower Street Enthusiast. Whether It'S Nos,Supercharger,Turbocharger Or A Big Inch Mountain Motor The "Original Street Twin" Can Handle It. Go With The Innovator Not The Imitator Mcleod Racing! |
| Description_SHO |
Clutch Kit |
| Throwout Bearing Included |
No |
| Pilot Bushing Material |
N/A |
| Flywheel Material |
Aluminum |
| Disc Diameter |
10.5In. |
| Ring Gear |
153 tooth |
| Alignment Tool Included |
Yes |
| Engine Balance |
Internal Balance |
| Pilot Bushing Included |
No |
| Hub Style |
Solid |
| Hardware Included |
Yes |
| Pressure Plate Style |
Diaphragm |
| Clutch Patterns |
10.5In. Borg & Beck. Street Twin Only |
| Engine |
1986-1997 SBC 305 & 350 1 PC SEAL |
| Clutch Usage |
Street |
| Disc Style |
Segmented Puck |
| Flywheel Included |
Yes |
| Application |
Chevrolet,Pontiac |
| Number of Discs |
Double |
| Spline |
1 1/8In. x 26 |
| Balance |
For Ext Balanced Also Order Weight Kit 560222 |
| Throwout Bearing Style |
Standard |
| Disc Material |
Ceramic |
| Horsepower Rating |
1200 |
| Length |
6.0000 |
| Width |
17.0000 |
| Height |
16.0000 |
| Weight |
42.0000 |
