4 in Gravity(R) LED Fog Lights are powered by KC's patented Gravity(R) Reflective Diode (GRD) and optical reflectors to deliver an incredible 150 lx at 10m using only .74A per light. KC's patented Gravity(R) Reflective Diode system aims LEDs into precision reflectors, capturing all light to project it forward.Diffused LensEach Light Sold IndividuallyEasy Attachment via Dzus clip or HardwareFlood Light PatternIP 68 Rated Waterproof Die-Cast Aluminum Housing Fog Beam- Provides a low, wide angle light pattern that increases short-range visibility. Ideal pattern for lighting pathways close to ground in low visibility conditions like dust, fog, snow and rain.Replaceable Colored Lens OptionsDurable Optical Quality Glass LensFog Beam Pattern5W 2.2 in MultiFunctional Accessory Light600 RAW lumens of light output for vibrant visibilityAmber Lens KC's Innovative adjustable mount allows users to easily adjust the aiming of lights horizontally for an optimum and consistent beam angle.
Specifications:
| Description_DEF |
Fog Light |
| Description_DES |
KC G4 Gravity LED 4in SAE ECE Fog 1-Light Universal |
| Description_FAB |
Constructed from an IP69 rated magnesium housing and polycarbonate lens creating a fully self contained LED light housing. |
| Description_FAB |
Fog Beam Pattern (SAE ECE Street Legal) |
| Description_FAB |
Lightweight Magnesium Housing for Maximum Heat Dissipation |
| Description_EXT |
KC HiLiTES 4 in Gravity LED G4 Universal LED Fog Lght feature bright CREE LEDs in a street legal fog beam pattern. Lightweight magnesium housing with optical reflectors, polycarbonate lens and universal adjustable bracket for easy mounting. |
| Description_INV |
KC Gravity LED |
| Description_MKT |
4 in Gravity(R) LED Fog Lights are powered by KC's patented Gravity(R) Reflective Diode (GRD) and optical reflectors to deliver an incredible 150 lx at 10m using only .74A per light. KC's patented Gravity(R) Reflective Diode system aims LEDs into precision reflectors, capturing all light to project it forward.Diffused LensEach Light Sold IndividuallyEasy Attachment via Dzus clip or HardwareFlood Light PatternIP 68 Rated Waterproof Die-Cast Aluminum Housing Fog Beam- Provides a low, wide angle light pattern that increases short-range visibility. Ideal pattern for lighting pathways close to ground in low visibility conditions like dust, fog, snow and rain.Replaceable Colored Lens OptionsDurable Optical Quality Glass LensFog Beam Pattern5W 2.2 in MultiFunctional Accessory Light600 RAW lumens of light output for vibrant visibilityAmber Lens KC's Innovative adjustable mount allows users to easily adjust the aiming of lights horizontally for an optimum and consistent beam angle. |
| Description_SHO |
Fog Light |
| Wattage |
10W |
| Lux |
150 |
| Light Temp |
5000K |
| Title |
KC Hilites 4 in Gravity LED G4 - Single Light - SAE/ECE - 10W Fog Beam |
| Amp Draw |
.74A |
| Beam Distance (Meters) |
245m |
| Raw Lumens |
866 lm |
| IP Rating |
IP68 |
| Voltage |
9V-32V |
| Lumens |
866 |
| Beam Pattern |
Fog |
| Prop 65 Yes/No |
No |
| Lux at 10 Meters |
150 lx |
| Add-On |
N/A |
| Product Dimensions |
W 3.94 in x H 3.94 in x D 3.23 in |
| Color Temperature |
5000K |
| Compliance |
SAE J583 ECE-R19 Street Legal |
| LED Source |
CREE LED |
| Lux at 10 Meters |
150 lx |
| Candela |
15,000 cd |
| Length |
6.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
