Description_ASM |
Ford 3.5L Ecoboost Gen II V6 |
Description_DEF |
Engine Piston |
Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.661 Bore, 1.240 CD, 0.905 Pin, Set of 1. |
Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
Description_INV |
JE Pistons, Piston |
Description_EXT |
JE, Ford, 3.5L EcoBoost Gen 2 V6, 3.661 in. Bore, 10.00:1, Inverted Dome/Dish, Left Piston |
Description_SHO |
Piston |
Description_TLE |
Ford 3.5L Eco Boost V6, 93.00 Bore, Dish, Set of 1 |
Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
Piston Pin Outside Diameter |
0.905 |
Piston Head Type |
Dish |
Engine |
3.5L ECOBOOST GEN 2 V6 |
Title |
JE Pistons - Ford, 3.5L EcoBoost Gen 2 V6, 93.00 mm Bore, Piston |
Make |
FORD |
Piston Pin Length |
2.250 |
Piston Pin Material |
5115 |
Compression Height |
1.240 |
Piston Pin Wall Thickness |
0.180 |
Engine - Web |
3.5L EcoBoost Gen 2 V6 |
Wrist Pin Outer Diameter |
0.905 |
Prop 65 (C, R or CR) |
CR |
Piston Series |
JE Pistons |
Ringset Included |
Yes |
Piston Material |
2618 |
Add-On |
905-073-MW |
Add-On |
JG1001-3661 |
Add-On |
905-2250-18-51C |
Engine Type |
ICE |
Out of Stock Message |
Call for Availability |
Industry |
Automotive |
Bore Diameter |
93.00 |
Forging Type |
FSR |
Title - Web |
JE Pistons Ford 3.5L EcoBoost Gen 2 V6 Piston - 93.00 mm Bore - 1.240 in. CH, -13.10 CC |
Product Market |
Sport Compact |
Oil Ring Thickness |
0.111 |
Wrist Pin Wall Thickness |
0.180 |
Prop 65 Yes/No |
Yes |
Piston Orientation |
Left |
Cylinder Head |
ECOBOOST V6 |
Piston Quantity |
1 |
Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
Product Type |
Engine Piston |
Piston Average Weight |
392 |
Second Compression Ring Thickness |
0.0480 |
Top Compression Ring Thickness |
0.0400 |
Piston Volume |
-13.10 |
Make - Web |
Ford |
Wrist Pin Length |
2.250 |
Ring Set Included |
Yes |
Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
Length |
5.0000 |
Width |
5.0000 |
Height |
5.0000 |
Weight |
1.0000 |
