Hedman Hedders has been manufacturing quality headers in the USA since 1954. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your Toyota exhaust system to bolt up, even if it is not perfectly aligned with the header collectors.
The super smooth, 1-1/2 in. primary tube design provides ample exhaust flow to help the carbureted 20R or 22R engine in your Toyota pickup truck or Celica produce maximum horsepower. The compact MID-LENGTH design provides excellent low-end torque for better streetability. These headers have a high temperature SATIN-BLACK ceramic finish that resists corrosion, and can withstand temperatures up to 1400 degree F. This finish is covered by a 5 year factory warranty, in addition to Hedman's standard lifetime header warranty.
Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed. Hedman Hedders is so confident in the quality of its headers that each set is factory backed by a Limited Lifetime Warranty against manufacturer defects.
Specifications:
| Description_ASM |
1975-1980 Toyota Celica 20R 2.2 Liter, 1981 Toyota Celica 22R 2.4 Liter, 1981 Toyota Celica 22R 2.4 Liter Transmission:Automatic, 1979-1980 Toyota Pickup 20R 2.2 Liter 4WD, 1975-1980 Toyota Pickup 20R 2.2 Liter RWD, 1981-1988 Toyota Pickup 22R 2.4 Liter 4WD, 1981-1988 Toyota Pickup 22R 2.4 Liter RWD |
| Description_DEF |
Exhaust Header |
| Description_DES |
Headers; '75-88 Toyota Pickup; 20R/22R (Carb); 1-1/2 in. Short Tube- Black Maxx |
| Description_FAB |
Handcrafted, Mild Steel Construction. |
| Description_FAB |
The Mid-Length Tube Header Design Provides Significantly More Low and Mid-range Power than Cast Manifolds, and Provide Better Ground Clearance And Component Compatibility Than Long Tube Headers. |
| Description_FAB |
Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors |
| Description_FAB |
Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters) |
| Description_FAB |
Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating! |
| Description_FAB |
Proud To Say, Made In The USA, Since 1954! |
| Description_INV |
HEDMAN TOYOTA TRUCK HEADERS-BLACK |
| Description_EXT |
Headers; '75-88 Toyota 2WD/4WD Pickup, '78-81 Celica; 20R/22R (Carb); 1-1/2 in. Short Tube; 2-1/2 in. Collector- Black-Maxx Satin Black Ceramic-Metallic Coated Mild Steel |
| Description_SHO |
HEADERS, COATED |
| Description_MKT |
Hedman Hedders has been manufacturing quality headers in the USA since 1954. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your Toyota exhaust system to bolt up, even if it is not perfectly aligned with the header collectors.
The super smooth, 1-1/2 in. primary tube design provides ample exhaust flow to help the carbureted 20R or 22R engine in your Toyota pickup truck or Celica produce maximum horsepower. The compact MID-LENGTH design provides excellent low-end torque for better streetability. These headers have a high temperature SATIN-BLACK ceramic finish that resists corrosion, and can withstand temperatures up to 1400 degree F. This finish is covered by a 5 year factory warranty, in addition to Hedman's standard lifetime header warranty.
Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed. Hedman Hedders is so confident in the quality of its headers that each set is factory backed by a Limited Lifetime Warranty against manufacturer defects.
|
| Air Conditioning |
Yes |
| Automatic Transmission - Column |
No |
| Automatic Transmission - Floor |
Yes |
| Bolts/Studs Included |
Yes |
| California Proposition 65 |
WARNING: Cancer & Reproductive Harm. For more info visit www.P65Warnings.ca.gov |
| Catalytic Converter(s) Included |
No |
| Collector Attachment |
2-1/2 in. |
| Collector Bolts Included |
Yes |
| Collector Diameter |
2-1/2 in. |
| Collector Size |
2-1/2 in. |
| Collector Style |
BALL and SOCKET Style (Gasketless) |
| Contents |
headers, head and collector flange gaskets (when applicable), mounting hardware |
| Crossover Pipe Included |
No |
| Cylinder Head |
Stock Profile Heads |
| Cylinder Head Port Shape |
Round |
| E.O. # |
No |
| Emissions Notes |
Not Legal For Street Use on '75-Later Model Years! Legal for off-road use only. |
| Engine |
Toyota 22R (Carbureted) |
| Engine |
Toyota 20R (Carbureted) |
| Exhaust System Dia |
2 in. |
| Finish |
BLACK MAXX Satin Black Ceramic-Metallic |
| Finish Type |
BLACK MAXX- Black Ceramic-Metallic Coating |
| Flange Style |
Standard |
| Flange Thickness |
0.375 in. |
| Gasket Or Seal Included |
Yes |
| Header Construction |
MILD STEEL- Standard-Duty |
| Header Fasteners Included |
Yes |
| Header Finish |
BLACK MAXX Satin Black Ceramic-Metallic |
| Header Material |
Mild Steel |
| Header Port Shape |
Round |
| Header Style |
Mid-Length Tube |
| Installation Hardware Included |
Yes |
| Manual Transmission - Column |
No |
| Manual Transmission - Floor |
Yes |
| Material |
Mild Steel |
| Motor Mounts Included |
No |
| Mounting Hardware Included |
Yes |
| Notes |
75-88 Toyota Pickup 20R/22R |
| Package Contents |
Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware |
| Port Shape |
Round |
| Power Steering |
Yes |
| Primary Tube Diameter (in) |
1.50 in. |
| Primary Tube Gauge |
16g |
| Quantity |
Sold individually. |
| Reducer Outlet Size |
2 in. |
| Reducers Included |
Yes |
| Replacement Gasket |
27610 |
| Replacement Head Flange Gasket |
27610 |
| Title |
HEDMAN HEDDERS TOYOTA P/U 75-81 2000 2200CC- BLACK MAXX |
| Tube Design |
Standard |
| Tube Diameter |
1-1/2 in. |
| Tube Length |
Mid-Length Tubes |
| Tube Material Thickness |
16g |
| Tube Size |
1-1/2 in. |
| Tube Style |
Mid-Length |
| Tuned |
No |
| Variations |
39400, 39408 |
| Weld-Up |
No |
| with A.I.R. System |
No |
| with EGR |
No |
| Y-Pipe Included |
No |
| Length |
8.0000 |
| Width |
14.0000 |
| Height |
20.0000 |
| Weight |
11.0000 |
