Developed from our off-road race shocks, FOX Factory Race Series combines race-proven technology with new, cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV.
Specifications:
Description_ASM |
Ram 2500/3500: 2014 - 2018 |
Description_DEF |
Steering Stabilizer |
Description_DES |
FACTORY RACE SERIES 2.0 ATS STABILIZER |
Description_EXT |
Application specific valving to maximize performance. |
Description_FAB |
Adjustable Through Shaft Stabilizer |
Description_FAB |
Performance Tuned For Vehicle Specific Application |
Description_FAB |
Aluminum Body Dissipates Heat Faster Than Steel |
Description_FAB |
Eliminates fluid displacement, delivering neutral and consistent damping of unwanted steering feedback |
Description_FAB |
External Reservoir With Compression Adjuster |
Description_FAB |
Black Anodized CNC Machined Aluminum Components |
Description_INV |
FACTORY RACE SERIES 2.0 ATS STABILIZER |
Description_SHO |
2.0 Stabilizer |
Description_MKT |
Developed from our off-road race shocks, FOX Factory Race Series combines race-proven technology with new, cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV. |
Description_LAB |
14-18 RAM 2500/3500 ATS Stabilizer, 8.2" Trav, 23.3" Ext, Through-Shaft, Ax |
Series |
Factory Race |
Body Diameter (in) |
2 |
Label Name |
14-18 RAM 2500/3500 ATS Stabilizer, 8.2" Trav, 23.3" Ext, Through-Shaft, Axle Mount |
Title |
FACTORY RACE SERIES 2.0 ATS STABILIZER |
Type |
Stabilizer |
Fox Catalog |
TRUCK |
Reservoir Type |
Piggyback |
Bottom Mount |
Eyelet |
Extended Length (in) |
23.27 |
Travel (in) |
8.20 |
Compressed Length (in) |
15.07 |
California Proposition 65 |
! Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
Top Mount (p/n) |
026-01-082 |
Body Material |
Aluminum |
Top Mount |
Axle Mount |
Length |
4.0000 |
Width |
4.0000 |
Height |
28.5000 |
Weight |
7.4000 |
