FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.
Specifications:
Description_DES |
FACTORY RACE 4.4 X 16 EXTERNAL BYPASS (5 TUBE) PIGGYBACK SHOCK (RIGHT) |
Description_DEF |
Suspension Shock Absorber |
Description_EXT |
Rebuildable and serviceable. Custom valving options availavble. |
Description_LAB |
4.4 FRS, EXBP, 5T, P/B, 16", RH |
Description_INV |
FOX 4.4 X 16.0 Bypass (5 Tube) Piggyback |
Description_FAB |
NEW proprietary Cerakote (R) protective ceramic coating over zinc plated basecoat |
Description_FAB |
17-4 H900 hard chrome plated stainless steel shaft |
Description_FAB |
Owner serviceable and rebuildable |
Description_FAB |
JM92 MIL-SPEC oil developed specifically for off-road racing |
Description_FAB |
Black Anodized CNC Machined Aluminum Components |
Description_SHO |
4.4 External Bypass |
Description_MKT |
FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done. |
Body Diameter (in) |
4.4 |
Shaft Size (in) |
1-1/4 |
Eyelet Length (in) |
2.05 |
Series |
Factory Race |
Adjuster Type |
External Bypass Clicker - Gen 3 |
Body Material |
Steel |
Bottom Mount |
Eyelet |
Bypass Tubes |
5 |
California Proposition 65 |
! Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
Compressed Length (in) |
27.89 |
Extended Length (in) |
43.92 |
Fox Catalog |
OFFROAD |
Label Name |
4.4 FRS, EXBP, 5T, P/B, 16", RH |
Mounting |
5/8 x 1-1/2 |
Reservoir Dimensions |
3.50 x 15.50 |
Reservoir Type |
Piggyback |
Title |
FACTORY RACE 4.4 X 16 EXTERNAL BYPASS (5 TUBE) PIGGYBACK SHOCK (RIGHT) |
Top Mount |
Eyelet |
Travel (in) |
16.03 |
Type |
External Bypass |
Valving |
807-24-901 |
Body Finish |
FOX Grey Cerakote |
Length |
8.7500 |
Width |
10.5000 |
Height |
50.0000 |
