Edelbrock part #77732 Valley Cover is designed for use with Edelbrock BV3 cylinder heads and intake manifolds with a 10.2" deck height and 4.84" bore spacing. In addition to covering the lifter valley, it also completes the cross flow coolant recovery system unique to the BV3 cylinder heads. This valley cover draws water from individual cylinders and combines them together at the thermostat housing for more uniform cooling of the cylinders. This design also delivers more consistent cylinder to cylinder cooling. A thermostat housing may be used for radiator return or, if a fill neck is used, a boss on the front can be drilled for a pipe thread fitting.
Specifications:
| Description_ABR |
Intake Mnfld |
| Description_ASM |
Chevrolet:Big-Block:496 (8.1L)/509 (8.3L)/540 (8.8L)/555 (9.0L)/565 (9.2L)/572 (9.3L)/582 (9.5L)/598 (9.7L)/632 (10.3L)/705 (11.5L) |
| Description_DEF |
Engine Intake Manifold |
| Description_LAB |
Valley Plate Big Victor 3 Big Block Chevy Tall Deck |
| Description_EXT |
Edelbrock Part Valley Cover is designed for use with Edelbrock BV3 cylinder heads and intake manifolds with a 10.2" deck height and 4.84" bore spacing |
| Description_INV |
Valley Cover BV3 4.84" Bore space 10.2 |
| Description_TRA |
Installation of this valley plates requires eight (8) 5/16" bolts per side for a total of 16. Bolts are not included. |
| Description_TRA |
Apply a continuous, 1/8" bead of automotive RTV silicone sealer to the end sealing surfaces on block and along bottom of the intake flange on the cylinder heads where they will meet the valley cover. |
| Description_MKT |
Edelbrock part #77732 Valley Cover is designed for use with Edelbrock BV3 cylinder heads and intake manifolds with a 10.2" deck height and 4.84" bore spacing. In addition to covering the lifter valley, it also completes the cross flow coolant recovery system unique to the BV3 cylinder heads. This valley cover draws water from individual cylinders and combines them together at the thermostat housing for more uniform cooling of the cylinders. This design also delivers more consistent cylinder to cylinder cooling. A thermostat housing may be used for radiator return or, if a fill neck is used, a boss on the front can be drilled for a pipe thread fitting. |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Length |
9.0000 |
| Width |
12.0000 |
| Height |
24.0000 |
| Weight |
20.0000 |
