The Edelbrock #5892 Sure Seat Valve Spring for Chrysler 383-400-413-440 V8 1969-79 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application.
Specifications:
| Description_ABR |
Valve Sprng |
| Description_ASM |
Chrysler:Big-Block B-Series:383 (6.3L)/400 (6.6L) |
| Description_DEF |
Engine Valve Spring Kit |
| Description_MKT |
The Edelbrock #5892 Sure Seat Valve Spring for Chrysler 383-400-413-440 V8 1969-79 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application. |
| Description_INV |
Edelbrock Sure Seat Valve Springs |
| Description_LAB |
Sure Seat Valve Springs for Chrysler 383-400-413-440 V8 1969-79 |
| Description_EXT |
The Edelbrock #5892 Sure Seat Valve Spring for Chrysler 383-400-413-440 V8 1969-79 O.E Cast iron cylinder heads are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. |
| Description_TRA |
Non-Rotator springs |
| Description_TRA |
Recommended Edelbrock Cam: #2192 |
| Inside Diameter |
1.120 |
| Spring Open Height |
0.430 |
| Coil Bind Height |
1.350 |
| Open Pressure |
200 |
| Damper Spring Included |
No |
| Outside Diameter |
1.550 |
| Material |
Chromium Silicon |
| Quantity |
Set of 16 |
| Springs Per Valve |
Single |
| Spring Type |
Cylindrical |
| Installed Pressure |
125 |
| Installed Height |
1.860 |
| Camshaft Type |
Hydraulic Flat Tappet |
| RGL |
WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Length |
2.0000 |
| Width |
3.0000 |
| Height |
12.0000 |
| Weight |
3.0000 |
