The Edelbrock #5877 Sure Seat Valve Spring for Chrysler 318-340-360 V8 1957-89 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application.
Specifications:
| Description_ABR |
Valve Sprng |
| Description_ASM |
Chrysler:Small-Block:273 (4.5L)/318 (5.2L)/340 (5.6L)/360 (5.9L) |
| Description_DEF |
Engine Valve Spring Kit |
| Description_EXT |
The Edelbrock #5877 Sure Seat Valve Spring for Chrysler 318-340-360 V8 1957-89 O.E Cast iron cylinder heads are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. |
| Description_LAB |
Sure Seat Valve Springs for Chrysler 318-340-360 V8 1957-89 |
| Description_INV |
Edelbrock Sure Seat Valve Springs |
| Description_MKT |
The Edelbrock #5877 Sure Seat Valve Spring for Chrysler 318-340-360 V8 1957-89 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application. |
| Description_TRA |
Non-Rotator springs |
| Description_TRA |
Recommended Edelbrock Cam: #2177 |
| Open Pressure |
178 |
| Outside Diameter |
1.494 |
| Installed Height |
1.650 |
| Spring Type |
Cylindrical |
| Inside Diameter |
1.080 |
| Damper Spring Included |
No |
| Material |
Chromium Silicon |
| Quantity |
Set of 16 |
| Installed Pressure |
90 |
| Coil Bind Height |
1.203 |
| Camshaft Type |
Hydraulic Flat Tappet |
| Spring Open Height |
0.375 |
| RGL |
WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Springs Per Valve |
Single |
| Length |
2.0000 |
| Width |
4.0000 |
| Height |
13.0000 |
| Weight |
3.0000 |
