3696 is sold individually, Short Body Siemens High Impedance (12.5 ohms) Fuel Injector with a flow rate of 60 lb/hr (630cc) @43.5psi. These injectors measure 37.25mm O-ring to O-ring centerline, feature Bosch style connectors with a Yellow Band around them for identification and are capable of up to 950HP @ 58psi when run as a set of 8 with ProFlo4. These injectors are offered as a replacement or upgrade for the ProFlo EFI Systems and are compatible with many OEM and aftermarket EFI systems.
Specifications:
| Description_ABR |
Fuel Injectr |
| Description_DEF |
Fuel Injector |
| Description_LAB |
Fuel Injector #3696 Siemens 60 lb/hr Sold Individually |
| Description_INV |
Fuel Injector 60 Lb/Hr Short (Single) |
| Description_EXT |
Short Body Siemens High Impedance (12.5 ohms) Fuel Injector with a flow rate of 60 lb/hr (630cc) @43.5psi. Bosch style connectors with a Blue Band around hem for identification. |
| Description_MKT |
3696 is sold individually, Short Body Siemens High Impedance (12.5 ohms) Fuel Injector with a flow rate of 60 lb/hr (630cc) @43.5psi. These injectors measure 37.25mm O-ring to O-ring centerline, feature Bosch style connectors with a Yellow Band around them for identification and are capable of up to 950HP @ 58psi when run as a set of 8 with ProFlo4. These injectors are offered as a replacement or upgrade for the ProFlo EFI Systems and are compatible with many OEM and aftermarket EFI systems. |
| Description_SLA |
Short Body Siemens High Impedance (12.5 ohms) Fuel Injector with a flow rate of 60 lb/hr (630cc) @43.5psi. These injectors measure 37.25mm O-ring to O-ring centerline, feature Bosch style connectors with a Yellow Band around them for identification. These injectors are offered as a replacement or upgrade for the ProFlo EFI Systems and are compatible with many OEM and aftermarket EFI systems. |
| Wiring Harness Included |
No |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Pressure Rating |
43.5 |
| Impedance |
12.5 |
| Quantity |
Sold Individually |
| Body Type |
Short |
| Injection Type |
EFI - Port Injection |
| Flow Rate |
60 |
| Color Coded |
Blue |
| Type |
Siemens |
| Length |
2.0000 |
| Width |
3.0000 |
| Height |
6.0000 |
| Weight |
1.0000 |
