Edelbrock 2561 Marine BBC Oval Port Intake Manifold

2 sold in last 8 days
Edelbrock
ds_BDVJ_2561
Engine Intake Manifold
$1,077.87
customers are viewing this product
Edelbrock 2561 Marine BBC Oval Port Intake Manifold
Details

Edelbrock part #2561 Performer RPM Q-Jet marine intake manifold is designed for spread-bore carbs but also works with Edelbrock square-bore carbs without adapter on street 396-502 c.i.d. Chevy V8's with large oval-port (1975 and earlier) heads. This marine intake features brass lined water passage and brass flange inserts to cover rear water openings. No provisions for hot air style chokes. Accepts divorced choke, late-model waterneck, air-conditioning, alternator and HEI equipment.

Specifications:

Description_ABR Intake Mnfld
Description_ASM Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L)
Description_DEF Engine Intake Manifold
Description_EXT Edelbrock Performer RPM Marine Q-Jet Intake Manifold for 396-502 Big-Block Chevrolet w/Oval Port Heads. All Cooling Water Passages are Lined with Brass to Prevent Corrosion. Accepts Q-jet or 4150-Style Square-Bore Marine Carburetor. Non-EGR
Description_MKT Edelbrock part #2561 Performer RPM Q-Jet marine intake manifold is designed for spread-bore carbs but also works with Edelbrock square-bore carbs without adapter on street 396-502 c.i.d. Chevy V8's with large oval-port (1975 and earlier) heads. This marine intake features brass lined water passage and brass flange inserts to cover rear water openings. No provisions for hot air style chokes. Accepts divorced choke, late-model waterneck, air-conditioning, alternator and HEI equipment.
Description_LAB Performer RPM 4V/Q-JET Marine Intake Manifold for Big-Block Chevy-Oval port
Description_INV Marine BBC Oval Port Intake Manifold
Description_TRA Recommended intake gasket: Edelbrock #7203
Description_TRA Will not fit under stock hood of Corvette, 1964-67 Chevelle, or 1967-81 Camaro.
Description_TRA Manifold height: A-4.45", B-6.0"
Description_TRA Carb pad height: 5.22"
Description_TRA Carb recommendations: Edelbrock AVS2 or Performer Series 650-800 cfm
Description_TRA Port exit dimensions: 1.60"w x 1.94"t
Description_TRA Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.
Description_TRA Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Gasket Or Seal Included No
Basic Operating RPM Range 1500-6500
Center Maximum Height 5.220
Front Maximum Height 4.450
RGL WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Vehicle Model Chevrolet
Grade Type Performance
EGR Port No - For Oval Port
Material Aluminum
Finish Satin
Flange Type 4150
Single Or Dual Plane Type Dual
CNC Ported No
Series Performer RPM
Rear Maximum Height 6.000
Length 12.0000
Width 7.0000
Height 24.0000
Weight 24.0000
