Edelbrock's Annular Flow Booster technology brings superior fuel atomization to all high-horsepower small- and big-block engines with the AVS2 800 CFM EnduraShine Electric Choke Carburetor #19134 that is calibrated to make power. Annular Flow Boosters deliver near EFI-like drivability that you can feel as soon as you step on the gas. Fuel distribution is refined by eight equally spaced orifices in the booster rings that replace down-leg boosters which simply dump raw fuel into the venturi. Flat spots are completely eliminated, and throttle response in the low- to mid-RPM range is improved tremendously without sacrificing that top-end power that Edelbrock is known for. The AVS2 is unaffected by engine backfires since there are no power valves to blow out. For fast and simple part-throttle tuning, metering rods and springs can be changed in seconds without carburetor removal or fuel draining. AVS2 carbs have the unique ability to "hold a tune" when compared to other carburetors. Your tuning and adjustments stay unchanged, so performance remains consistent. Updated primary and secondary booster clusters in the AVS2 offer the most accurate and up-to-date calibration available for today's fuels and octane levels. Additionally, the unique Qwik-Tune Secondary Air Valve allows for limitless calibration of the secondary circuit. Adjustments can be with simple hand tools in seconds to suit your application. The AVS2 features a two-piece ease-of-tuning design that allows you to make float level adjustments or replace internal components without draining the fuel from the carburetor or removing it from the engine. The AVS2 800 CFM is available with a manual choke in satin finish (#1912) or electric choke with satin finish (#1913). All AVS2 Series carburetors are designed, manufactured, assembled and calibrated by Edelbrock in the USA.
Specifications:
| Description_ABR |
AVS2 Carb |
| Description_DEF |
Carburetor |
| Description_EXT |
Edelbrock's Annular Flow Booster technology brings superior fuel atomization to all high-horsepower small- and big-block engines with the AVS2 800 CFM Electric Choke Carburetor, EnduraShine finish #19134 |
| Description_INV |
AVS2 800 CFM Carb w/Elec Choke #19134 |
| Description_LAB |
AVS2 Carburetor #19134 800 CFM With Electric Choke, EnduraShine Finish (Non-EGR) |
| Description_SLA |
Our innovative Annular Flow Booster technology brings superior fuel atomization to all high-horsepower small- and big-block engines with the 800 CFM AVS2 EnduraShine Electric Choke Carburetor #19134 that is specially calibrated to make power. Annular Flow Boosters deliver near EFI-like drivability that you can feel as soon as you step on the gas. Fuel distribution is refined by eight equally spaced orifices in the booster rings that replace down-leg boosters which simply dump raw fuel into the venturi. Flat spots are completely eliminated, and throttle response in the low- to mid-RPM range is improved tremendously with no sacrificing of that top-end power that Edelbrock is known for. |
| Description_TRA |
Manual choke AVS2 carburetors cannot be converted to electric choke. |
| Description_MKT |
Edelbrock's Annular Flow Booster technology brings superior fuel atomization to all high-horsepower small- and big-block engines with the AVS2 800 CFM EnduraShine Electric Choke Carburetor #19134 that is calibrated to make power. Annular Flow Boosters deliver near EFI-like drivability that you can feel as soon as you step on the gas. Fuel distribution is refined by eight equally spaced orifices in the booster rings that replace down-leg boosters which simply dump raw fuel into the venturi. Flat spots are completely eliminated, and throttle response in the low- to mid-RPM range is improved tremendously without sacrificing that top-end power that Edelbrock is known for. The AVS2 is unaffected by engine backfires since there are no power valves to blow out. For fast and simple part-throttle tuning, metering rods and springs can be changed in seconds without carburetor removal or fuel draining. AVS2 carbs have the unique ability to "hold a tune" when compared to other carburetors. Your tuning and adjustments stay unchanged, so performance remains consistent. Updated primary and secondary booster clusters in the AVS2 offer the most accurate and up-to-date calibration available for today's fuels and octane levels. Additionally, the unique Qwik-Tune Secondary Air Valve allows for limitless calibration of the secondary circuit. Adjustments can be with simple hand tools in seconds to suit your application. The AVS2 features a two-piece ease-of-tuning design that allows you to make float level adjustments or replace internal components without draining the fuel from the carburetor or removing it from the engine. The AVS2 800 CFM is available with a manual choke in satin finish (#1912) or electric choke with satin finish (#1913). All AVS2 Series carburetors are designed, manufactured, assembled and calibrated by Edelbrock in the USA. |
| Finish |
EnduraShine |
| Maximum Flow Rating |
800 |
| Material |
Aluminum |
| EGR Port |
No |
| Booster Type |
annular |
| Primary Jet Diameter |
0.104 |
| Flange Shape |
Square |
| Body Height |
3.25 |
| Bore Diameter |
Primary Bore 1.75; Secondary Bore 1.75 |
| Main Venturi Diameter |
1.525 |
| Barrel Quantity |
4 Barrel |
| Condition |
New |
| Series |
AVS2 |
| Secondary Jet Diameter |
0.104 |
| Choke Type |
Electric |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Spring Force |
5" Hg (Orange) |
| Gasket Or Seal Included |
Yes |
| Metering Rod Size |
.065 x .052 |
| Length |
7.0000 |
| Width |
7.0000 |
| Height |
13.0000 |
| Weight |
10.0000 |
