Edelbrock's AVS2 #1906-BP with Electric Choke is a special Black Plasma finished 650 CFM street carb with Annular Flow Booster technology for near-EFI-like drivability that you can feel as soon as you step on the gas. The AVS2 1906-CP features an annular ring with eight evenly spaced orifices that replaces the standard single brass tube (down-leg) fuel feed. The AVS2 booster ring distributes fuel into the airflow stream with an even spray that eliminates flat spots and greatly improves throttle response in the low-to mid-RPM range without sacrificing top-end power. The Black Plasma finish is applied is a 7 stage process to ensure the most durable and brilliant finish possible. Black Plasma has a deep gloss that reflects the surrounding colors for a beautiful effect.
Specifications:
| Description_ABR |
CARB |
| Description_DEF |
Carburetor |
| Description_DES |
Edelbrock AVS2 650 CFM Carburetor #1906-BP Electric Choke, Black Plasma Finish |
| Description_EXT |
Edelbrock's AVS2 #1906-BP with Electric Choke is a special Black Plasma coated 650 CFM street carb with Annular Flow Booster technology for near-EFI-like drivability that you can feel as soon as you step on the gas. |
| Description_INV |
Edelbrock AVS2 650 CFM Carburetor Black |
| Description_FAB |
Annular Flow Booster technology |
| Description_FAB |
Beautiful and Durable Black Plasma coating |
| Description_FAB |
Easy to maintain finish |
| Description_FAB |
Electric Choke |
| Description_MKT |
Edelbrock's AVS2 #1906-BP with Electric Choke is a special Black Plasma finished 650 CFM street carb with Annular Flow Booster technology for near-EFI-like drivability that you can feel as soon as you step on the gas. The AVS2 1906-CP features an annular ring with eight evenly spaced orifices that replaces the standard single brass tube (down-leg) fuel feed. The AVS2 booster ring distributes fuel into the airflow stream with an even spray that eliminates flat spots and greatly improves throttle response in the low-to mid-RPM range without sacrificing top-end power. The Black Plasma finish is applied is a 7 stage process to ensure the most durable and brilliant finish possible. Black Plasma has a deep gloss that reflects the surrounding colors for a beautiful effect. |
| Description_LAB |
Edelbrock AVS2 650 CFM Carburetor #1906-BP Electric Choke, Black Plasma Finish |
| Description_SHP |
None |
| Description_TRA |
Thunder Series AVS2 Carbs will work with Ford automatic overdrive trans (AOD) when used with Lokar bracket SRK-4000 |
| Description_TRA |
Edelbrock carburetors are not calibrated for or compatible with alcohol, race or E85 pump fuel. The use of alcohol or E85 in your Edelbrock carburetor will damage your carburetor and void your warranty. |
| Description_TRA |
The use of a new fuel filter between the fuel pump and carburetor is required. Failure to do so will void the manufacturer's warranty of the carburetor |
| Description_TRA |
You must use Edelbrock Adapter #2732 when installing a Performer Series carburetor on certain Edelbrock intake manifolds |
| Accel Pump Capacity |
Adjustable - 25cc/31cc/39cc |
| Spring Force |
5" Hg (Orange) |
| Throttle Linkage Type |
Universal |
| Bore Diameter |
Primary Bore 1.44; Secondary Bore 1.75 |
| Universal Or Specific Fit |
Universal |
| Fuel Compatibility |
Gas |
| Inlet Fitting Thread Diameter |
5/8" -20 |
| Material |
Aluminum |
| Condition |
New |
| Series |
AVS2 |
| Booster Type |
Annular |
| EGR Port |
No |
| Finish |
Black Plasma |
| Metering Rod Size |
.070 x .037 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Length |
7.0000 |
| Width |
7.0000 |
| Height |
13.0000 |
| Weight |
9.0000 |
