The Edelbrock 18259 Remanufactured Thunder Series AVS 650 CFM manual choke carburetor has been designed and calibrated to deliver optimum off-road performance. Several characteristics make the 18259 Remanufactured Thunder Series AVS 650 CFM manual choke carburetor an outstanding street performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The third characteristic is the primary and secondary booster clusters that are utilized offer the most accurate and up-to-date calibration available for today's fuels and octane levels. Fourth the unique Thunder Series' Qwik-Tune Secondary Air Valve allows for limitless calibration of the secondary circuit with simple hand tools while on your vehicle. It's quick. It's simple. It's effective. It can be easily adjusted - in seconds - to suit your application.. no extra parts required to achieve optimum performance. Simply put the Edelbrock 18259 Remanufactured Thunder Series AVS 650 CFM manual choke carburetor is undeniably the most innovative and dependable street performance carburetor available today.
Specifications:
| Description_ABR |
CARB |
| Description_DEF |
Carburetor |
| Description_INV |
Reman Edelbrock Thunder AVS 650 CFM Carb |
| Description_EXT |
Edelbrock Remanufactured Thunder Series AVS 650 cfm, Off-Road Square-Flange, Manual Choke Carburetor (non-EGR) |
| Description_LAB |
Reman Thunder AVS Carb #18259 650 CFM With Manual Choke, Satin Finish (Non-EGR) |
| Description_MKT |
The Edelbrock 18259 Remanufactured Thunder Series AVS 650 CFM manual choke carburetor has been designed and calibrated to deliver optimum off-road performance. Several characteristics make the 18259 Remanufactured Thunder Series AVS 650 CFM manual choke carburetor an outstanding street performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The third characteristic is the primary and secondary booster clusters that are utilized offer the most accurate and up-to-date calibration available for today's fuels and octane levels. Fourth the unique Thunder Series' Qwik-Tune Secondary Air Valve allows for limitless calibration of the secondary circuit with simple hand tools while on your vehicle. It's quick. It's simple. It's effective. It can be easily adjusted - in seconds - to suit your application.. no extra parts required to achieve optimum performance. Simply put the Edelbrock 18259 Remanufactured Thunder Series AVS 650 CFM manual choke carburetor is undeniably the most innovative and dependable street performance carburetor available today. |
| Description_TRA |
Manual choke AVS Carbs cannot be converted to electric choke |
| Description_TRA |
Thunder Series AVS Carbs will work with Ford automatic overdrive trans (AOD) when used with Lokar bracket SRK-4000 |
| Description_TRA |
Edelbrock carburetors are not calibrated for or compatible with alcohol, race or E85 pump fuel. The use of alcohol or E85 in your Edelbrock carburetor will damage your carburetor and void your warranty. |
| Flange Shape |
Square Bore |
| Air Cleaner Flange Diameter |
5.125 |
| Maximum Flow Rating |
650 |
| Barrel Quantity |
4 |
| EGR Port |
No |
| Finish |
Satin |
| Primary Jet Diameter |
0.095 |
| Body Height |
3.25 |
| Base Width |
5.937 |
| Mounting Hole Diameter |
0.355 |
| Grade Type |
Performance |
| Base Length |
6.25 |
| Body Material |
Aluminum |
| Metering Rod Power Tip Diameter |
0.047 |
| Main Venturi Diameter |
1.190 |
| Inlet Fitting Thread Diameter |
0.625 |
| Gasket Or Seal Included |
Yes |
| Float Drop |
1.0 |
| Street Legal |
No |
| Choke Type |
Manual |
| Adjustable Float Level |
No |
| Center Hung Floats |
No |
| Small Venturi Diameter |
1.630 |
| Mounting Hardware Included |
No |
| Spacer Included |
No |
| Float Material |
Brass |
| Linkage Attached |
No |
| Secondary Jet Diameter |
0.098 |
| Mounting Hole Quantity |
8 |
| RGL |
WARNING: This product can expose you to Zinc, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Metering Rod Length |
3.15 |
| Float Level |
0.437 |
| Marine Approved |
No |
| Length |
7.0000 |
| Width |
7.0000 |
| Height |
13.0000 |
| Weight |
9.0000 |
