| Description_ABR |
SuperchrgrKt |
| Description_ASM |
Chevrolet:Small-Block Gen V LT1:376 (6.2L) |
| Description_DEF |
Supercharger Kit |
| Description_EXT |
Edelbrock supercharger Stage I System WITHOUT TUNER #156640 for 2014-2020 Silverado 1500, Sierra 1500, Escalade, Escalade ESV, Yukon Denali & Yukon Denali XL applications with a 6.2L L86 Gen V engine |
| Description_INV |
Edelbrock supercharger #156640 |
| Description_LAB |
Edelbrock Supercharger #156640 15-20 GM SUV & 14-18 GM Truck Gen V 6.2L W/O Tune |
| Description_TRA |
Supercharger systems without tuners are not eligible for supplemental warranty and are only emissions-legal when used with the correct Edelbrock program. For safety, the Edelbrock program retains the factory vehicle speed limiter setting. #156630 and #156640 Supercharger systems sold without tuners are only emissions legal when used with the correct Edelbrock program. The Edelbrock program will disable the Flex-Fuel E85 capability (if originally equipped). For safety, the Edelbrock program retains the factory vehicle speed limiter setting. Supercharger #15663, #156630, #15664 & #156640 will fit GM SUVs & GM full size trucks with the air box on the right side (USA passenger side) and will not fit hybrid powertrains. |
| Description_TRA |
Calibrations, Tuners, or Programs supplied with supercharger systems are only compatible with vehicles designed for use in the United States or Canada. Edelbrock does not offer calibration support for any vehicle designed for use outside of the United States or Canada. |
| Description_SLA |
This addition to Edelbrock's expanding line of superchargers is highlighted by significant improvements for Chevrolet/GMC/Cadillac 2015-2020 SUVs and 2014-2018 full size trucks with the GM 6.2L L86 V8 engine. This is a bolt-on performance kit that is emissions legal in all 50 states and produces 576 horsepower with 537 ft-lbs of torque at the rear wheel. This is the perfect power adder whether you plan to tow a trailer, haul heavier loads, or you just want to feel your truck/SUV come to life without sacrificing daily drivability! The new Edelbrock supercharger Kit #156640 for Chevy/GMC/Cadillac trucks and SUVs is a complete redesign of our #1565 and #1566 kits featuring an all-new manifold that now houses R2650 TVS rotors for unparalleled efficiency and reliability. The Edelbrock supercharger Kit for the 6.2L V8 fits under the stock hood with absolutely no cutting or modifications required. And if you're concerned about the effect on MPG, the increase in power comes with little to no loss in fuel economy thanks to the supercharger's integrated bypass valve that mitigates parasitic power loss during normal driving. This new kit is a true bolt-on that requires no additional modifications to the stock 6.2L engine. For those who want more power, the R2650 supercharger can support more than 1,000 horsepower at the flywheel with the right combination of parts. This Edelbrock supercharger features a self-contained lubrication system with a 100,000-mile service interval with a high-capacity Dual-Pass 3-Core (DP3C) integrated intercooler and comes finished in a durable black powder-coating that blends nicely with the engine. Each kit includes a complete set of preformed hoses, hardware and a full-color manual that provides clear step-by-step instructions for ease of installation. This system is designed and manufactured in the USA and is covered by a free 3-year/36,000-mile warranty. |
| Description_MKT |
This addition to Edelbrock's expanding line of superchargers is highlighted by significant improvements for Chevrolet/GMC/Cadillac 2015-2020 SUVs and 2014-2018 full size trucks with the GM 6.2L L86 V8 engine. This is a bolt-on performance kit that is emissions legal in all 50 states and produces 576 horsepower with 537 ft-lbs of torque at the rear wheel. This is the perfect power adder whether you plan to tow a trailer, haul heavier loads, or you just want to feel your truck/SUV come to life without sacrificing daily drivability! The new Edelbrock supercharger Kit #156640 for Chevy/GMC/Cadillac trucks and SUVs is a complete redesign of our #1565 and #1566 kits featuring an all-new manifold that now houses R2650 TVS rotors for unparalleled efficiency and reliability. The Edelbrock supercharger Kit for the 6.2L V8 fits under the stock hood with absolutely no cutting or modifications required. And if you're concerned about the effect on MPG, the increase in power comes with little to no loss in fuel economy thanks to the supercharger's integrated bypass valve that mitigates parasitic power loss during normal driving. This new kit is a true bolt-on that requires no additional modifications to the stock 6.2L engine. For those who want more power, the R2650 supercharger can support more than 1,000 horsepower at the flywheel with the right combination of parts. This Edelbrock supercharger features a self-contained lubrication system with a 100,000-mile service interval with a high-capacity Dual-Pass 3-Core (DP3C) integrated intercooler and comes finished in a durable black powder-coating that blends nicely with the engine. Each kit includes a complete set of preformed hoses, hardware and a full-color manual that provides clear step-by-step instructions for ease of installation. This system is designed and manufactured in the USA and is covered by a free 3-year/36,000-mile warranty. |
| Outside Pulley Diameter |
3.5 |
| Oil Capacity |
150 |
| Housing Material |
Cast Aluminum |
| Finish |
Black Powder Coated |
| Universal Or Specific Fit |
Specific |
| Harmonic Balancer Diameter |
7.4 |
| Calibration |
No |
| Quantity |
Kit |
| System Type |
Stage 1 - Street System |
| Hose Included |
Yes |
| Center Housing Cooling Type |
Intercooler |
| Rotor Type |
Eaton TVS 2650 |
| Mounting Hardware Included |
Yes |
| Vehicle Model |
Escalade |
| RGL |
WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Mounting Bracket Included |
Yes |
| Pulley Belt Width |
6-Rib |
| Gasket Or Seal Included |
Yes |
| Air Filter Included |
Yes |
| Internal Step Up |
Yes |
| Length |
10.0000 |
| Width |
19.0000 |
| Height |
25.0000 |
| Weight |
105.0000 |
