The Edelbrock Supercharger System #1528 for your 2015-18 Wrangler delivers 317 RWHP and 277 RWTQ for a manual and 303 RWHP and 262 RWTQ for an automatic. This Supercharger is exclusively for the Pentastar 3.6L V6 Engine featuring a unique design with minimal components make it possible to fit under the stock hood. The core of each system is the Eaton Gen VI 1320 TVS rotating assembly with a four-lobe design and 160 degrees of twist for maximum flow, minimum temperature rise and quiet operation for excellent drivability. We also designed our superchargers with an integrated bypass valve to help eliminate parasitic loss under light throttle, improving mileage potential. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path that for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. Part #1528 will require the ECM and TCM to be sent into Edelbrock for modification, no handheld programmer is included with these systems. This is an 8-10 day process/waiting period from the time they are received.
Specifications:
| Description_ABR |
SuperchrgrKt |
| Description_ASM |
Jeep:Pentastar V6:220 (3.6L) |
| Description_DEF |
Supercharger Kit |
| Description_INV |
Edelbrock Jeep Wrangler 3.6L V6 2015-18 |
| Description_EXT |
Edelbrock part #1528 Jeep Wrangler 3.6L V6 2015-18 Pentastar Supercharger, delivers 317 RWHP and 277 RWTQ for a MANUAL and 303 RWHP and 262 RWTQ for an auto. |
| Description_MKT |
The Edelbrock Supercharger System #1528 for your 2015-18 Wrangler delivers 317 RWHP and 277 RWTQ for a manual and 303 RWHP and 262 RWTQ for an automatic. This Supercharger is exclusively for the Pentastar 3.6L V6 Engine featuring a unique design with minimal components make it possible to fit under the stock hood. The core of each system is the Eaton Gen VI 1320 TVS rotating assembly with a four-lobe design and 160 degrees of twist for maximum flow, minimum temperature rise and quiet operation for excellent drivability. We also designed our superchargers with an integrated bypass valve to help eliminate parasitic loss under light throttle, improving mileage potential. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path that for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. Part #1528 will require the ECM and TCM to be sent into Edelbrock for modification, no handheld programmer is included with these systems. This is an 8-10 day process/waiting period from the time they are received. |
| Description_LAB |
Edelbrock Stage 1 Supercharger #1528 For 2015-18 Jeep Wrangler JK 3.6L W/ Tune |
| Description_TRA |
Supercharger systems without tuners are not eligible for supplemental warranty and are only emissions-legal when used with the correct Edelbrock program. For safety, the Edelbrock program retains the factory vehicle speed limiter setting. |
| Description_TRA |
Calibrations, Tuners, or Programs supplied with supercharger systems are only compatible with vehicles designed for use in the United States or Canada. Edelbrock does not offer calibration support for any vehicle designed for use outside of the United States or Canada. |
| Maximum Pressure Reading |
8 |
| Outside Pulley Diameter |
2.625 |
| Hose Included |
Yes |
| Calibration |
Yes |
| Housing Material |
Cast Aluminum |
| Oil Capacity |
125 |
| Maximum Boost Pressure |
8 |
| Finish |
Black Powder Coated |
| Quantity |
Kit |
| Universal Or Specific Fit |
Specific |
| Maximum Horsepower |
317RW (Manual Trans)/285RW (Auto Trans); With Stock Tires |
| Center Housing Cooling Type |
Intercooler |
| Pulley Belt Width |
6-Rib |
| Harmonic Balancer Diameter |
6.1 |
| Internal Step Up |
Yes |
| System Type |
Stage 1 - Street System |
| Mounting Bracket Included |
Yes |
| Air Filter Included |
Yes |
| Mounting Hardware Included |
Yes |
| Fuel Injector Type |
42 |
| RGL |
WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Maximum Torque |
277RW (Manual Trans)/235RW (Auto Trans); With Stock Tires |
| Vehicle Model |
Wrangler |
| Gasket Or Seal Included |
Yes |
| Rotor Type |
Eaton TVS 1320 |
| Length |
18.0000 |
| Width |
26.0000 |
| Height |
33.0000 |
| Weight |
91.0000 |
